7JQ6 | pdb_00007jq6

The Phi-28 gp11 DNA packaging Motor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.274 (Depositor), 0.268 (DCC)
  • R-Value Work:
    0.241 (Depositor), 0.242 (DCC)
  • R-Value Observed:
    0.243 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7JQ6

This is version 1.2 of the entry. See complete history

Literature

Atomistic basis of force generation, translocation, and coordination in a viral genome packaging motor.

Pajak, J.Dill, E.Reyes-Aldrete, E.White, M.A.Kelch, B.A.Jardine, P.J.Arya, G.Morais, M.C.

(2021) Nucleic Acids Res 49: 6474-6488

  • DOI: https://doi.org/10.1093/nar/gkab372
  • Primary Citation Related Structures:
    7JQ6, 7JQ7, 7JQP

  • PubMed Abstract:

    Double-stranded DNA viruses package their genomes into pre-assembled capsids using virally-encoded ASCE ATPase ring motors. We present the first atomic-resolution crystal structure of a multimeric ring form of a viral dsDNA packaging motor, the ATPase of the asccφ28 phage, and characterize its atomic-level dynamics via long timescale molecular dynamics simulations. Based on these results, and previous single-molecule data and cryo-EM reconstruction of the homologous φ29 motor, we propose an overall packaging model that is driven by helical-to-planar transitions of the ring motor. These transitions are coordinated by inter-subunit interactions that regulate catalytic and force-generating events. Stepwise ATP binding to individual subunits increase their affinity for the helical DNA phosphate backbone, resulting in distortion away from the planar ring towards a helical configuration, inducing mechanical strain. Subsequent sequential hydrolysis events alleviate the accumulated mechanical strain, allowing a stepwise return of the motor to the planar conformation, translocating DNA in the process. This type of helical-to-planar mechanism could serve as a general framework for ring ATPases.


  • Organizational Affiliation
    • Dept. of Mechanical Engineering and Materials Science, Duke University, Durham, NC 27708, USA.

Macromolecule Content

  • Total Structure Weight: 226.41 kDa
  • Atom Count: 15,452
  • Modeled Residue Count: 1,829
  • Deposited Residue Count: 1,870
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Encapsidation protein
A, B, C, D, E
374Lactococcus phage asccphi28Mutation(s): 0
UniProt
Find proteins for A0ACD6B8F1 (Lactococcus phage asccphi28)
Explore A0ACD6B8F1
Go to UniProtKB:  A0ACD6B8F1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B8F1
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4

Query on SO4



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
H [auth B]
I [auth B]
J [auth B]
F [auth A],
G [auth A],
H [auth B],
I [auth B],
J [auth B],
K [auth C],
L [auth C],
M [auth D],
N [auth E],
O [auth E],
P [auth E]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D, E
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.274 (Depositor), 0.268 (DCC)
  • R-Value Work:  0.241 (Depositor), 0.242 (DCC)
  • R-Value Observed: 0.243 (Depositor)
Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 135α = 90
b = 135β = 90
c = 276.7γ = 120
Software Package:
Software NamePurpose
HKL-2000data scaling
SHELXphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM095516
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM122979

Revision History  (Full details and data files)

  • Version 1.0: 2021-06-16
    Type: Initial release
  • Version 1.1: 2021-07-14
    Changes: Database references
  • Version 1.2: 2024-10-30
    Changes: Data collection, Database references, Structure summary
