7JK6

Structure of Drosophila ORC in the active conformation


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural mechanism for replication origin binding and remodeling by a metazoan origin recognition complex and its co-loader Cdc6.

Schmidt, J.M.Bleichert, F.

(2020) Nat Commun 11: 4263-4263

  • DOI: https://doi.org/10.1038/s41467-020-18067-7
  • Primary Citation of Related Structures:
    7JGR, 7JGS, 7JK2, 7JK3, 7JK4, 7JK5, 7JK6

  • PubMed Abstract:

    Eukaryotic DNA replication initiation relies on the origin recognition complex (ORC), a DNA-binding ATPase that loads the Mcm2-7 replicative helicase onto replication origins. Here, we report cryo-electron microscopy (cryo-EM) structures of DNA-bound Drosophila ORC with and without the co-loader Cdc6. These structures reveal that Orc1 and Orc4 constitute the primary DNA binding site in the ORC ring and cooperate with the winged-helix domains to stabilize DNA bending. A loop region near the catalytic Walker B motif of Orc1 directly contacts DNA, allosterically coupling DNA binding to ORC's ATPase site. Correlating structural and biochemical data show that DNA sequence modulates DNA binding and remodeling by ORC, and that DNA bending promotes Mcm2-7 loading in vitro. Together, these findings explain the distinct DNA sequence-dependencies of metazoan and S. cerevisiae initiators in origin recognition and support a model in which DNA geometry and bendability contribute to Mcm2-7 loading site selection in metazoans.


  • Organizational Affiliation

    Friedrich Miescher Institute for Biomedical Research, Maulbeerstrasse 66, Basel, 4058, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 4A [auth D]462Drosophila melanogasterMutation(s): 0
Gene Names: Orc4Dmel\CG2917DmORC4ORCORC4rDmORCCG2917Dmel_CG2917
UniProt
Find proteins for Q9W102 (Drosophila melanogaster)
Explore Q9W102
Go to UniProtKB:  Q9W102
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9W102
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 5B [auth E]460Drosophila melanogasterMutation(s): 0
Gene Names: Orc5CG7833
UniProt
Find proteins for Q24169 (Drosophila melanogaster)
Explore Q24169
Go to UniProtKB:  Q24169
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ24169
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 1C [auth A]488Drosophila melanogasterMutation(s): 0
Gene Names: Orc1CG10667
UniProt
Find proteins for O16810 (Drosophila melanogaster)
Explore O16810
Go to UniProtKB:  O16810
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO16810
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 2D [auth B]618Drosophila melanogasterMutation(s): 0
Gene Names: Orc2CG3041
UniProt
Find proteins for Q24168 (Drosophila melanogaster)
Explore Q24168
Go to UniProtKB:  Q24168
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ24168
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 3E [auth C]721Drosophila melanogasterMutation(s): 0
Gene Names:
UniProt
Find proteins for Q7K2L1 (Drosophila melanogaster)
Explore Q7K2L1
Go to UniProtKB:  Q7K2L1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7K2L1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 6257Drosophila melanogasterMutation(s): 0
Gene Names: Orc6CG1584
UniProt
Find proteins for Q9Y1B2 (Drosophila melanogaster)
Explore Q9Y1B2
Go to UniProtKB:  Q9Y1B2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y1B2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research Council (ERC)SwitzerlandERC-STG-757909

Revision History  (Full details and data files)

  • Version 1.0: 2020-09-09
    Type: Initial release
  • Version 1.1: 2024-03-06
    Changes: Data collection, Database references
