7H0S

Crystal structure of SARS-CoV-2 NSP3 Macrodomain in complex with ASAP-0013769-001


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.29 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.166
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Group deposition of SARS-CoV-2 NSP3 Macrodomain in complex with inhibitors from the ASAP AViDD centre

Aschenbrenner, J.C.Fearon, D.Tomlinson, C.W.E.Marples, P.G.Fairhead, M.Balcomb, B.H.Chandran, A.V.Godoy, A.S.Koekemoer, L.Lithgo, R.M.Ni, X.Thompson, W.Wang, S.Wild, C.Williams, E.P.Winokan, M.Walsh, M.A.von Delft, F.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Papain-like protease nsp3
A, B
170Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
Gene Names: rep1a-1b
EC: 3.4.19.12 (PDB Primary Data), 3.4.22 (PDB Primary Data)
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1ANI
Query on A1ANI

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
4-{[(1S)-1-(2-acetamido-1,3-benzothiazol-6-yl)-2-methylpropyl]amino}-N-ethyl-7H-pyrrolo[2,3-d]pyrimidine-6-carboxamide
C22 H25 N7 O2 S
AZJTVWHOYVAUON-SFHVURJKSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.29 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.166
  • R-Value Observed: 0.168
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 37.927α = 90
b = 33.338β = 97.19
c = 125.088γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
Aimlessdata scaling
PHASERphasing
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesU19AI171399

Revision History  (Full details and data files)

  • Version 1.0: 2024-05-15
    Type: Initial release
