7GTZ

PanDDA analysis group deposition of ground-state model of PTP1B, using pre-clustering, cluster5

PDB DOI: https://doi.org/10.2210/pdb7GTZ/pdb
Deposition Group: G_1002285 (ground state) ExploreG_1002285

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2024-01-05 Released: 2024-01-31
Deposition Author(s): Mehlman, T., Ginn, H.M., Keedy, D.A.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), Helmholtz Association

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.241
R-Value Work: 0.214
R-Value Observed: 0.215

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

PanDDA analysis group deposition of ground-state model

Mehlman, T., Ginn, H.M., Keedy, D.A.

To be published.

Macromolecule Content

Total Structure Weight: 37.47 kDa
Atom Count: 2,563
Modelled Residue Count: 284
Deposited Residue Count: 321
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Tyrosine-protein phosphatase non-receptor type 1	A	321	Homo sapiens	Mutation(s): 2 Gene Names: PTPN1, PTP1B EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for P18031 (Homo sapiens) Explore P18031 Go to UniProtKB: P18031
PHAROS: P18031 GTEx: ENSG00000196396
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P18031
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TRS Query on TRS Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.241
R-Value Work: 0.214
R-Value Observed: 0.215
Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 89.583	α = 90
b = 89.583	β = 90
c = 106.257	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
PHASER	phasing
XDS	data reduction

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2024-01-31

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM133769
Helmholtz Association	Germany	VH-NG-19-02

Revision History (Full details and data files)

Version 1.0: 2024-01-31
Type: Initial release
