7FXZ

Crystal Structure of human FABP4 in complex with 4-hexylsulfanyl-1-(3-pyridylmethyl)-6-sulfanyl-1,3,5-triazin-2-one

• PDB DOI: https://doi.org/10.2210/pdb7FXZ/pdb
• Deposition Group: G_1002264 ExploreG_1002264

• Classification: LIPID BINDING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2023-04-27 Released: 2023-06-14
• Deposition Author(s): Ehler, A., Benz, J., Obst, U., Rudolph, M.G.
• Funding Organization(s): F. Hoffmann-La Roche LTD

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.03 Å
• R-Value Free: 0.175
• R-Value Work: 0.145
• R-Value Observed: 0.147

Starting Model: other

Literature

Crystal Structure of a human FABP4 complex

Obst, U., Magnone, C., Kuhn, B., Rudolph, M.G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 15.64 kDa
• Atom Count: 1,377
• Modelled Residue Count: 133
• Deposited Residue Count: 135
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fatty acid-binding protein, adipocyte	A	135	Homo sapiens	Mutation(s): 0  Gene Names: FABP4
UniProt & NIH Common Fund Data Resources
Find proteins for P15090 (Homo sapiens) Explore P15090  Go to UniProtKB:  P15090
PHAROS:  P15090 GTEx:  ENSG00000170323

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
UO3 (Subject of Investigation/LOI)	B [auth A]	4-hexylsulfanyl-1-(pyridin-3-ylmethyl)-6-sulfanyl-1$l^{4},3,5-triazacyclohexa-1,3,5-trien-2-ol C15 H21 N4 O S2 AAGCVGJIZNRQQT-UHFFFAOYSA-N
SO4	C [auth A], F [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
FMT	D [auth A], E [auth A]	FORMIC ACID C H2 O2 BDAGIHXWWSANSR-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.03 Å
• R-Value Free: 0.175
• R-Value Work: 0.145
• R-Value Observed: 0.147
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 32.813	α = 90
b = 53.748	β = 90
c = 74.709	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-06-14
Deposition Author(s): Ehler, A., Benz, J., Obst, U., Rudolph, M.G.

---

Funding Organization	Location	Grant Number
F. Hoffmann-La Roche LTD	Switzerland	--

Revision History

• Version 1.0: 2023-06-14
  Type: Initial release

• Version 1.1: 2024-04-03
  Changes: Data collection, Refinement description
