7F87 | pdb_00007f87

Crystal structure of housekeeping sortase SrtA bound with self derived tripeptide from Lactobacillus rhamnosus GG

PDB DOI: https://doi.org/10.2210/pdb7F87/pdb

Classification: TRANSFERASE
Organism(s): Lacticaseibacillus rhamnosus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-07-01 Released: 2022-07-06
Deposition Author(s): Pratap, S., Krishnan, V.
Funding Organization(s): Department of Biotechnology (DBT, India)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.69 Å
R-Value Free:
0.214 (Depositor), 0.218 (DCC)
R-Value Work:
0.181 (Depositor), 0.192 (DCC)
R-Value Observed:
0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7F87

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of housekeeping sortase SrtA bound with self derived tripeptide from Lactobacillus rhamnosus GG

Pratap, S., Krishnan, V.

To be published.

Macromolecule Content

Total Structure Weight: 33.69 kDa
Atom Count: 2,442
Modeled Residue Count: 296
Deposited Residue Count: 304
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Class A sortase	A, B	149	Lacticaseibacillus rhamnosus	Mutation(s): 0 Gene Names: F5976_12260, F8M46_11135, FEZ43_04140, GKD16_09085, HWN39_00700, LRHP540_01088, PY91_04000
UniProt
Find proteins for A0A0E3D3H8 (Lacticaseibacillus rhamnosus) Explore A0A0E3D3H8 Go to UniProtKB: A0A0E3D3H8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0E3D3H8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Self Derived Peptide	C [auth F], D [auth G]	3	Lacticaseibacillus rhamnosus	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A], F [auth A], G [auth A], H [auth B], I [auth B]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth B] Focus chain I [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth B] Focus chain I [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain J [auth B] MOL2 format, chain J [auth B] mmCIF format, chain J [auth B]	J [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain J [auth B] Interactions & Density Focus chain J [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CSD Query on CSD	A, B	L-PEPTIDE LINKING	C₃ H₇ N O₄ S		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.69 Å
R-Value Free: 0.214 (Depositor), 0.218 (DCC)
R-Value Work: 0.181 (Depositor), 0.192 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.608	α = 90
b = 55.674	β = 103.22
c = 75.312	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-07-06

Deposition Author(s):

Funding Organization	Location	Grant Number
Department of Biotechnology (DBT, India)	India	BT/PR5891/BRB/10/1098/2012

Revision History (Full details and data files)

Version 1.0: 2022-07-06
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Refinement description
Version 1.2: 2024-11-20
Changes: Structure summary
