7F7A | pdb_00007f7a

Crystal structure of Non-specific class-C acid phosphatase from Sphingobium sp. RSMS bound to Adenine at pH 9

PDB DOI: https://doi.org/10.2210/pdb7F7A/pdb

Classification: HYDROLASE
Organism(s): Sphingobium sp. 20006FA
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-06-28 Released: 2022-07-06
Deposition Author(s): Gaur, N.K., Kumar, A., Sunder, S., Mukhopadhyaya, R., Makde, R.D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.251 (Depositor), 0.250 (DCC)
R-Value Work:
0.192 (Depositor), 0.200 (DCC)
R-Value Observed:
0.195 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7F7A

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Non-Specific Class-c acidphosphatase from Sphingobium sp. RSMS

Gaur, N.K., Kumar, A., Sunder, S., Mukhopadhyaya, R., Makde, R.D.

To be published.

Macromolecule Content

Total Structure Weight: 31.37 kDa
Atom Count: 1,893
Modeled Residue Count: 254
Deposited Residue Count: 296
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acid phosphatase	A	296	Sphingobium sp. 20006FA	Mutation(s): 0 Gene Names: A8O16_10785

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ADE (Subject of Investigation/LOI) Query on ADE Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	ADENINE C₅ H₅ N₅ GFFGJBXGBJISGV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free: 0.251 (Depositor), 0.250 (DCC)
R-Value Work: 0.192 (Depositor), 0.200 (DCC)
R-Value Observed: 0.195 (Depositor)

Space Group: I 4₁ 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 168.581	α = 90
b = 168.581	β = 90
c = 168.581	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Aimless	data scaling
MR-Rosetta	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2022-07-06

Deposition Author(s):

Mukhopadhyaya, R.

Revision History (Full details and data files)

Version 1.0: 2022-07-06
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Structure summary
