7EU1

The cryo-EM structure of A. thaliana Pol IV-RDR2 holoenzyme


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.86 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Pol IV and RDR2: A two-RNA-polymerase machine that produces double-stranded RNA.

Huang, K.Wu, X.X.Fang, C.L.Xu, Z.G.Zhang, H.W.Gao, J.Zhou, C.M.You, L.L.Gu, Z.X.Mu, W.H.Feng, Y.Wang, J.W.Zhang, Y.

(2021) Science 374: 1579-1586

  • DOI: https://doi.org/10.1126/science.abj9184
  • Primary Citation of Related Structures:
    7EU0, 7EU1

  • PubMed Abstract:

    DNA methylation affects gene expression and maintains genome integrity. The DNA-dependent RNA polymerase IV (Pol IV), together with the RNA-dependent RNA polymerase RDR2, produces double-stranded small interfering RNA precursors essential for establishing and maintaining DNA methylation in plants. We determined the cryo–electron microscopy structures of the Pol IV–RDR2 holoenzyme and the backtracked transcription elongation complex. These structures reveal that Pol IV and RDR2 form a complex with their active sites connected by an interpolymerase channel, through which the Pol IV–generated transcript is handed over to the RDR2 active site after being backtracked, where it is used as the template for double-stranded RNA (dsRNA) synthesis. Our results describe a ‘backtracking-triggered RNA channeling’ mechanism underlying dsRNA synthesis and also shed light on the evolutionary trajectory of eukaryotic RNA polymerases.


  • Organizational Affiliation

    Key Laboratory of Synthetic Biology, CAS Center for Excellence in Molecular Plant Sciences, Shanghai Institute of Plant Physiology and Ecology, Chinese Academy of Sciences, Shanghai 200032, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase IV subunit 11,510Arabidopsis thalianaMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q9LQ02 (Arabidopsis thaliana)
Explore Q9LQ02
Go to UniProtKB:  Q9LQ02
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9LQ02
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases IV and V subunit 21,172Arabidopsis thalianaMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q9LK40 (Arabidopsis thaliana)
Explore Q9LK40
Go to UniProtKB:  Q9LK40
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9LK40
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 3319Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q39211 (Arabidopsis thaliana)
Explore Q39211
Go to UniProtKB:  Q39211
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ39211
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II and IV subunit 5AD [auth E]205Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for O81098 (Arabidopsis thaliana)
Explore O81098
Go to UniProtKB:  O81098
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO81098
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 6AE [auth F]144Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q9FJ98 (Arabidopsis thaliana)
Explore Q9FJ98
Go to UniProtKB:  Q9FJ98
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FJ98
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 8BF [auth H]146Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q9M1A8 (Arabidopsis thaliana)
Explore Q9M1A8
Go to UniProtKB:  Q9M1A8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9M1A8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 9AG [auth I]114Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q6NLH0 (Arabidopsis thaliana)
Explore Q6NLH0
Go to UniProtKB:  Q6NLH0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6NLH0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 10H [auth J]71Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q8LFJ6 (Arabidopsis thaliana)
Explore Q8LFJ6
Go to UniProtKB:  Q8LFJ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8LFJ6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 11I [auth K]116Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q38859 (Arabidopsis thaliana)
Explore Q38859
Go to UniProtKB:  Q38859
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ38859
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases II, IV and V subunit 12J [auth L]51Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q9FLM8 (Arabidopsis thaliana)
Explore Q9FLM8
Go to UniProtKB:  Q9FLM8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FLM8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
RNA-dependent RNA polymerase 2K [auth M]1,133Arabidopsis thalianaMutation(s): 0
EC: 2.7.7.48
UniProt
Find proteins for O82504 (Arabidopsis thaliana)
Explore O82504
Go to UniProtKB:  O82504
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO82504
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
L [auth A]
N [auth A]
O [auth B]
P [auth C]
Q [auth I]
L [auth A],
N [auth A],
O [auth B],
P [auth C],
Q [auth I],
R [auth I],
S [auth J],
T [auth L]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
M [auth A],
U [auth M]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.86 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2021-12-29
    Type: Initial release
  • Version 1.1: 2022-02-16
    Changes: Database references
  • Version 1.2: 2024-06-05
    Changes: Data collection
