7AQR

Cryo-EM structure of Arabidopsis thaliana Complex-I (peripheral arm)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.91 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

A ferredoxin bridge connects the two arms of plant mitochondrial complex I.

Klusch, N.Senkler, J.Yildiz, O.Kuhlbrandt, W.Braun, H.P.

(2021) Plant Cell 33: 2072-2091

  • DOI: https://doi.org/10.1093/plcell/koab092
  • Primary Citation of Related Structures:
    7AQQ, 7AQR, 7AQW, 7AR7, 7AR8, 7AR9, 7ARB, 7ARC, 7ARD

  • PubMed Abstract:

    Mitochondrial complex I is the main site for electron transfer to the respiratory chain and generates much of the proton gradient across the inner mitochondrial membrane. Complex I is composed of two arms, which form a conserved L-shape. We report the structures of the intact, 47-subunit mitochondrial complex I from Arabidopsis thaliana and the 51-subunit complex I from the green alga Polytomella sp., both at around 2.9 Å resolution. In both complexes, a heterotrimeric γ-carbonic anhydrase domain is attached to the membrane arm on the matrix side. Two states are resolved in A. thaliana complex I, with different angles between the two arms and different conformations of the ND1 (NADH dehydrogenase subunit 1) loop near the quinol binding site. The angle appears to depend on a bridge domain, which links the peripheral arm to the membrane arm and includes an unusual ferredoxin. We propose that the bridge domain participates in regulating the activity of plant complex I.


  • Organizational Affiliation

    Department of Structural Biology, Max-Planck-Institute of Biophysics, Frankfurt 60438, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] iron-sulfur protein 7, mitochondrialA [auth B]218Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for Q42577 (Arabidopsis thaliana)
Explore Q42577
Go to UniProtKB:  Q42577
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ42577
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] iron-sulfur protein 3B [auth C]190Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for Q95748 (Arabidopsis thaliana)
Explore Q95748
Go to UniProtKB:  Q95748
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ95748
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase subunit 7C [auth D]394Arabidopsis thalianaMutation(s): 1
EC: 7.1.1.2
UniProt
Find proteins for P93306 (Arabidopsis thaliana)
Explore P93306
Go to UniProtKB:  P93306
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP93306
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] flavoprotein 2, mitochondrialD [auth E]255Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for O22769 (Arabidopsis thaliana)
Explore O22769
Go to UniProtKB:  O22769
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO22769
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] flavoprotein 1, mitochondrialE [auth F]486Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for Q9FNN5 (Arabidopsis thaliana)
Explore Q9FNN5
Go to UniProtKB:  Q9FNN5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FNN5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] iron-sulfur protein 1, mitochondrialF [auth G]748Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for Q9FGI6 (Arabidopsis thaliana)
Explore Q9FGI6
Go to UniProtKB:  Q9FGI6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FGI6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] iron-sulfur protein 8-A, mitochondrialG [auth I]222Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for Q42599 (Arabidopsis thaliana)
Explore Q42599
Go to UniProtKB:  Q42599
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ42599
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 9, mitochondrialH [auth P]402Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9SK66 (Arabidopsis thaliana)
Explore Q9SK66
Go to UniProtKB:  Q9SK66
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SK66
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] iron-sulfur protein 4, mitochondrialI [auth Q]154Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9FJW4 (Arabidopsis thaliana)
Explore Q9FJW4
Go to UniProtKB:  Q9FJW4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FJW4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] iron-sulfur protein 6, mitochondrialJ [auth R]110Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9M9M6 (Arabidopsis thaliana)
Explore Q9M9M6
Go to UniProtKB:  Q9M9M6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9M9M6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 2K [auth S]97Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9FIJ2 (Arabidopsis thaliana)
Explore Q9FIJ2
Go to UniProtKB:  Q9FIJ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FIJ2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Acyl carrier protein 2, mitochondrialL [auth U]126Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for O80800 (Arabidopsis thaliana)
Explore O80800
Go to UniProtKB:  O80800
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO80800
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Probable NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 5, mitochondrialM [auth V]169Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9FLX7 (Arabidopsis thaliana)
Explore Q9FLX7
Go to UniProtKB:  Q9FLX7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FLX7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 6N [auth W]133Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9LHI0 (Arabidopsis thaliana)
Explore Q9LHI0
Go to UniProtKB:  Q9LHI0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9LHI0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 13-AO [auth Z]143Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q8RWA7 (Arabidopsis thaliana)
Explore Q8RWA7
Go to UniProtKB:  Q8RWA7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RWA7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
Probable NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 12P [auth q]159Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9M9M9 (Arabidopsis thaliana)
Explore Q9M9M9
Go to UniProtKB:  Q9M9M9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9M9M9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
FurryQ [auth r]131Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q9SD78 (Arabidopsis thaliana)
Explore Q9SD78
Go to UniProtKB:  Q9SD78
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SD78
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NDP
Query on NDP

Download Ideal Coordinates CCD File
AA [auth P]NADPH DIHYDRO-NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H30 N7 O17 P3
ACFIXJIJDZMPPO-NNYOXOHSSA-N
8Q1
Query on 8Q1

Download Ideal Coordinates CCD File
CA [auth W]S-[2-({N-[(2R)-2-hydroxy-3,3-dimethyl-4-(phosphonooxy)butanoyl]-beta-alanyl}amino)ethyl] dodecanethioate
C23 H45 N2 O8 P S
MVHUOSAYFQKAMT-NRFANRHFSA-N
FMN
Query on FMN

Download Ideal Coordinates CCD File
T [auth F]FLAVIN MONONUCLEOTIDE
C17 H21 N4 O9 P
FVTCRASFADXXNN-SCRDCRAPSA-N
SF4
Query on SF4

Download Ideal Coordinates CCD File
R [auth B]
U [auth F]
W [auth G]
X [auth G]
Y [auth I]
R [auth B],
U [auth F],
W [auth G],
X [auth G],
Y [auth I],
Z [auth I]
IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-UHFFFAOYSA-N
FES
Query on FES

Download Ideal Coordinates CCD File
S [auth E],
V [auth G]
FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
BA [auth R]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.91 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Max Planck SocietyGermany--

Revision History  (Full details and data files)

  • Version 1.0: 2021-12-08
    Type: Initial release
