6ZZ1

Crystal structure of MLKL executioner domain in complex with a covalent inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.64 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.197
  • R-Value Observed: 0.198

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Locking mixed-lineage kinase domain-like protein in its auto-inhibited state prevents necroptosis.

Rubbelke, M.Fiegen, D.Bauer, M.Binder, F.Hamilton, J.King, J.Thamm, S.Nar, H.Zeeb, M.

(2020) Proc Natl Acad Sci U S A 117: 33272-33281

  • DOI: https://doi.org/10.1073/pnas.2017406117
  • Primary Citation of Related Structures:
    6ZLE, 6ZPR, 6ZVO, 6ZZ1

  • PubMed Abstract:

    As an alternative pathway of controlled cell death, necroptosis can be triggered by tumor necrosis factor via the kinases RIPK1/RIPK3 and the effector protein mixed-lineage kinase domain-like protein (MLKL). Upon activation, MLKL oligomerizes and integrates into the plasma membrane via its executioner domain. Here, we present the X-ray and NMR costructures of the human MLKL executioner domain covalently bound via Cys86 to a xanthine class inhibitor. The structures reveal that the compound stabilizes the interaction between the auto-inhibitory brace helix α6 and the four-helix bundle by stacking to Phe148. An NMR-based functional assay observing the conformation of this helix showed that the F148A mutant is unresponsive to the compound, providing further evidence for the importance of this interaction. Real-time and diffusion NMR studies demonstrate that xanthine derivatives inhibit MLKL oligomerization. Finally, we show that the other well-known MLKL inhibitor Necrosulfonamide, which also covalently modifies Cys86, must employ a different mode of action.


  • Organizational Affiliation

    Medicinal Chemistry, Boehringer Ingelheim Pharma GmbH & Co. KG, 88397 Biberach an der Riss, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Mixed lineage kinase domain-like protein
A, B
153Homo sapiensMutation(s): 0
Gene Names: MLKL
UniProt & NIH Common Fund Data Resources
Find proteins for Q8NB16 (Homo sapiens)
Explore Q8NB16
Go to UniProtKB:  Q8NB16
PHAROS:  Q8NB16
GTEx:  ENSG00000168404
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8NB16
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
QOK (Subject of Investigation/LOI)
Query on QOK

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
7-(2-methoxyethoxymethyl)-1,3-dimethyl-purine-2,6-dione
C11 H16 N4 O4
BSIZPWZVMIVPIN-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.64 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.197
  • R-Value Observed: 0.198
  • Space Group: P 43
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.709α = 90
b = 56.709β = 90
c = 90.501γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
autoPROCdata reduction
XDSdata reduction
autoPROCdata scaling
Aimlessdata scaling
DIMPLEphasing
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-12-23
    Type: Initial release
  • Version 1.1: 2021-01-06
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Database references, Refinement description
