6ZJY

Respiratory complex I from Thermus thermophilus, NAD+ dataset, minor state


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 5.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Key role of quinone in the mechanism of respiratory complex I.

Gutierrez-Fernandez, J.Kaszuba, K.Minhas, G.S.Baradaran, R.Tambalo, M.Gallagher, D.T.Sazanov, L.A.

(2020) Nat Commun 11: 4135-4135

  • DOI: https://doi.org/10.1038/s41467-020-17957-0
  • Primary Citation of Related Structures:
    6I0D, 6I1P, 6Q8O, 6Q8W, 6Q8X, 6Y11, 6ZIY, 6ZJL, 6ZJN, 6ZJY

  • PubMed Abstract:

    Complex I is the first and the largest enzyme of respiratory chains in bacteria and mitochondria. The mechanism which couples spatially separated transfer of electrons to proton translocation in complex I is not known. Here we report five crystal structures of T. thermophilus enzyme in complex with NADH or quinone-like compounds. We also determined cryo-EM structures of major and minor native states of the complex, differing in the position of the peripheral arm. Crystal structures show that binding of quinone-like compounds (but not of NADH) leads to a related global conformational change, accompanied by local re-arrangements propagating from the quinone site to the nearest proton channel. Normal mode and molecular dynamics analyses indicate that these are likely to represent the first steps in the proton translocation mechanism. Our results suggest that quinone binding and chemistry play a key role in the coupling mechanism of complex I.


  • Organizational Affiliation

    Institute of Science and Technology Austria, Am Campus 1, A-3400, Klosterneuburg, Austria.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 1A [auth 1]438Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56222 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56222
Go to UniProtKB:  Q56222
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56222
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 2B [auth 2]181Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56221 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56221
Go to UniProtKB:  Q56221
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56221
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 3C [auth 3]783Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56223 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56223
Go to UniProtKB:  Q56223
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56223
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 4D [auth 4]409Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56220 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56220
Go to UniProtKB:  Q56220
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56220
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 5E [auth 5]207Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56219 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56219
Go to UniProtKB:  Q56219
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56219
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 6F [auth 6]181Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56218 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56218
Go to UniProtKB:  Q56218
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56218
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 9G [auth 9]182Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56224 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56224
Go to UniProtKB:  Q56224
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56224
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 15H [auth 7]129Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q5SKZ7 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SKZ7
Go to UniProtKB:  Q5SKZ7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SKZ7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 7I [auth A]119Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56217 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56217
Go to UniProtKB:  Q56217
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56217
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 10176Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56225 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56225
Go to UniProtKB:  Q56225
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56225
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 1195Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56226 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56226
Go to UniProtKB:  Q56226
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56226
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 12606Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56227 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56227
Go to UniProtKB:  Q56227
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56227
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 13469Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56228 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56228
Go to UniProtKB:  Q56228
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56228
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 14427Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q56229 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q56229
Go to UniProtKB:  Q56229
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56229
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 8O [auth H]365Thermus thermophilusMutation(s): 0
EC: 7.1.1
Membrane Entity: Yes
UniProt
Find proteins for Q60019 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q60019
Go to UniProtKB:  Q60019
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ60019
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SF4
Query on SF4

Download Ideal Coordinates CCD File
P [auth 1]
R [auth 3]
S [auth 3]
T [auth 3]
V [auth 6]
P [auth 1],
R [auth 3],
S [auth 3],
T [auth 3],
V [auth 6],
W [auth 9],
X [auth 9]
IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-UHFFFAOYSA-N
FES
Query on FES

Download Ideal Coordinates CCD File
Q [auth 2],
U [auth 3]
FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 5.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTMDFF
RECONSTRUCTIONRELION2.0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Medical Research Council (MRC, United Kingdom)United KingdomMC_U105674180

Revision History  (Full details and data files)

  • Version 1.0: 2020-09-02
    Type: Initial release
  • Version 1.1: 2024-05-01
    Changes: Data collection, Database references, Refinement description
