6YHK | pdb_00006yhk

Crystal structure of full-length CNFy (C866S) from Yersinia pseudotuberculosis


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.242 (Depositor), 0.246 (DCC)
  • R-Value Work:
    0.205 (Depositor), 0.209 (DCC)
  • R-Value Observed:
    0.207 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6YHK

This is version 1.3 of the entry. See complete history

Literature

Crystal structure of bacterial cytotoxic necrotizing factor CNF Y reveals molecular building blocks for intoxication.

Chaoprasid, P.Lukat, P.Muhlen, S.Heidler, T.Gazdag, E.M.Dong, S.Bi, W.Ruter, C.Kirchenwitz, M.Steffen, A.Jansch, L.Stradal, T.E.B.Dersch, P.Blankenfeldt, W.

(2021) EMBO J 40: e105202-e105202

  • DOI: https://doi.org/10.15252/embj.2020105202
  • Primary Citation Related Structures:
    6YHK, 6YHL, 6YHM, 6YHN

  • PubMed Abstract:

    Cytotoxic necrotizing factors (CNFs) are bacterial single-chain exotoxins that modulate cytokinetic/oncogenic and inflammatory processes through activation of host cell Rho GTPases. To achieve this, they are secreted, bind surface receptors to induce endocytosis and translocate a catalytic unit into the cytosol to intoxicate host cells. A three-dimensional structure that provides insight into the underlying mechanisms is still lacking. Here, we determined the crystal structure of full-length Yersinia pseudotuberculosis CNF Y . CNF Y consists of five domains (D1-D5), and by integrating structural and functional data, we demonstrate that D1-3 act as export and translocation module for the catalytic unit (D4-5) and for a fused β-lactamase reporter protein. We further found that D4, which possesses structural similarity to ADP-ribosyl transferases, but had no equivalent catalytic activity, changed its position to interact extensively with D5 in the crystal structure of the free D4-5 fragment. This liberates D5 from a semi-blocked conformation in full-length CNF Y , leading to higher deamidation activity. Finally, we identify CNF translocation modules in several uncharacterized fusion proteins, which suggests their usability as a broad-specificity protein delivery tool.


  • Organizational Affiliation
    • Institute of Infectiology, Center for Molecular Biology of Inflammation (ZMBE), University of Münster, Münster, Germany.

Macromolecule Content

  • Total Structure Weight: 115.82 kDa
  • Atom Count: 7,921
  • Modeled Residue Count: 994
  • Deposited Residue Count: 1,018
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cytotoxic necrotizing factor1,018Yersinia pseudotuberculosisMutation(s): 1
Gene Names: cnf
UniProt
Find proteins for A0A0N9JNY6 (Yersinia pseudotuberculosis)
Explore A0A0N9JNY6
Go to UniProtKB:  A0A0N9JNY6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0N9JNY6
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4

Query on SO4



Download:Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
E [auth A]
F [auth A]
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
CL

Query on CL



Download:Ideal Coordinates CCD File
K [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.242 (Depositor), 0.246 (DCC)
  • R-Value Work:  0.205 (Depositor), 0.209 (DCC)
  • R-Value Observed: 0.207 (Depositor)
Space Group: I 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.153α = 90
b = 180.416β = 90
c = 220.761γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-12-30
    Type: Initial release
  • Version 1.1: 2021-01-20
    Changes: Database references
  • Version 1.2: 2021-02-24
    Changes: Database references
  • Version 1.3: 2024-05-01
    Changes: Data collection, Database references, Refinement description
