6YE1

Human Ecto-5'-nucleotidase (CD73) in complex with the AMPCP derivative A894 (compound 2n in publication) in the closed form (crystal form IV)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.66 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.193
  • R-Value Observed: 0.197

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Discovery of Potent and Selective Methylenephosphonic Acid CD73 Inhibitors.

Sharif, E.U.Kalisiak, J.Lawson, K.V.Miles, D.H.Newcomb, E.Lindsey, E.A.Rosen, B.R.Debien, L.P.P.Chen, A.Zhao, X.Young, S.W.Walker, N.P.Strater, N.Scaletti, E.R.Jin, L.Xu, G.Leleti, M.R.Powers, J.P.

(2021) J Med Chem 64: 845-860

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c01835
  • Primary Citation of Related Structures:
    6YE1, 6YE2

  • PubMed Abstract:

    Solid tumors are often associated with high levels of extracellular ATP. Ectonucleotidases catalyze the sequential hydrolysis of ATP to adenosine, which potently suppresses T-cell and NK-cell functions via the adenosine receptors (A 2a and A 2b ). The ectonucleotidase CD73 catalyzes the conversion of AMP to adenosine. Thus, increased CD73 enzymatic activity in the tumor microenvironment is a potential mechanism for tumor immune evasion and has been associated with poor prognosis in the clinic. CD73 inhibition is anticipated to restore immune function by skirting this major mechanism of adenosine generation. We have developed a series of potent and selective methylenephosphonic acid CD73 inhibitors via a structure-based design. Key binding interactions of the known inhibitor adenosine-5'-(α,β-methylene)diphosphate (AMPCP) with hCD73 provided the foundation for our early designs. The structure-activity relationship study guided by this structure-based design led to the discovery of 4a , which exhibits excellent potency against CD73, exquisite selectivity against related ectonucleotidases, and a favorable pharmacokinetic profile.


  • Organizational Affiliation

    Arcus Biosciences, Inc., 3928 Point Eden Way, Hayward, California 94545, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
5'-nucleotidase
A, B
532Homo sapiensMutation(s): 5
Gene Names: NT5ENT5NTE
EC: 3.1.3.5 (PDB Primary Data), 3.1.3.99 (UniProt), 3.1.3.89 (UniProt), 3.1.3.35 (UniProt), 3.1.3.91 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P21589 (Homo sapiens)
Explore P21589
Go to UniProtKB:  P21589
PHAROS:  P21589
GTEx:  ENSG00000135318
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21589
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.66 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.193
  • R-Value Observed: 0.197
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.03α = 90
b = 232.12β = 90
c = 53.79γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
BUSTERrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
BUSTERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-01-20
    Type: Initial release
  • Version 1.1: 2021-01-27
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-11-06
    Changes: Structure summary
