6Y6I | pdb_00006y6i

lipopolysaccharide outer core galactosyltransferase WaaB and UDP complex

PDB DOI: https://doi.org/10.2210/pdb6Y6I/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Salmonella enterica subsp. enterica serovar Typhimurium str. LT2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-02-26 Released: 2021-03-31
Deposition Author(s): Zhang, Z.Y., Ashworth, G., Wang, Z.S., Zhu, X.F., Dong, C.J.
Funding Organization(s): Wellcome Trust

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.92 Å
R-Value Free:
0.213 (Depositor), 0.213 (DCC)
R-Value Work:
0.164 (Depositor), 0.166 (DCC)
R-Value Observed:
0.166 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6Y6I

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structural insights into the lipopolysaccharide outer core galactosyltransferase WaaB

Zhang, Z.Y., Ashworth, G., Wang, Z.S., Zhu, X.F., Dong, C.J.

To be published.

Macromolecule Content

Total Structure Weight: 41.48 kDa
Atom Count: 3,200
Modeled Residue Count: 358
Deposited Residue Count: 361
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lipopolysaccharide 1,6-galactosyltransferase	A	361	Salmonella enterica subsp. enterica serovar Typhimurium str. LT2	Mutation(s): 0 Gene Names: rfaB, waaB, STM3719 EC: 2.4.1
UniProt
Find proteins for Q06994 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)) Explore Q06994 Go to UniProtKB: Q06994
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q06994
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UDP (Subject of Investigation/LOI) Query on UDP Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	URIDINE-5'-DIPHOSPHATE C₉ H₁₄ N₂ O₁₂ P₂ XCCTYIAWTASOJW-XVFCMESISA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.92 Å
R-Value Free: 0.213 (Depositor), 0.213 (DCC)
R-Value Work: 0.164 (Depositor), 0.166 (DCC)
R-Value Observed: 0.166 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 104.44	α = 90
b = 104.44	β = 90
c = 89.64	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-03-31

Deposition Author(s):

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	WT106121MA

Revision History (Full details and data files)

Version 1.0: 2021-03-31
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Refinement description
