6WWL

KIF14[391-755] dimer two-heads-bound state - AMP-PNP in complex with a microtubule

  • Classification: MOTOR PROTEIN
  • Organism(s): Sus scrofa, Mus musculus
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2020-05-09 Released: 2021-05-05
  • Deposition Author(s): Benoit, M.P.M.H., Asenjo, A.B., Paydar, M., Dhakal, S., Kwok, B., Sosa, H.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), Natural Sciences and Engineering Research Council (NSERC, Canada), Canadian Cancer Society Research Institute, Fonds de Recherche du Quebec-Sante (FRSQ), Canadian Institutes of Health Research (CIHR), Simons Foundation, NYSTAR, Agouron Institute, National Institutes of Health/Office of the Director

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural basis of mechano-chemical coupling by the mitotic kinesin KIF14.

Benoit, M.P.M.H.Asenjo, A.B.Paydar, M.Dhakal, S.Kwok, B.H.Sosa, H.

(2021) Nat Commun 12: 3637-3637

  • DOI: https://doi.org/10.1038/s41467-021-23581-3
  • Primary Citation of Related Structures:
    6WWE, 6WWF, 6WWG, 6WWH, 6WWI, 6WWJ, 6WWK, 6WWL, 6WWM, 6WWN, 6WWO, 6WWP, 6WWQ, 6WWR, 6WWS, 6WWT, 6WWU, 6WWV, 7LVQ, 7LVR

  • PubMed Abstract:

    KIF14 is a mitotic kinesin whose malfunction is associated with cerebral and renal developmental defects and several cancers. Like other kinesins, KIF14 couples ATP hydrolysis and microtubule binding to the generation of mechanical work, but the coupling mechanism between these processes is still not fully clear. Here we report 20 high-resolution (2.7-3.9 Å) cryo-electron microscopy KIF14-microtubule structures with complementary functional assays. Analysis procedures were implemented to separate coexisting conformations of microtubule-bound monomeric and dimeric KIF14 constructs. The data provide a comprehensive view of the microtubule and nucleotide induced KIF14 conformational changes. It shows that: 1) microtubule binding, the nucleotide species, and the neck-linker domain govern the transition between three major conformations of the motor domain; 2) an undocked neck-linker prevents the nucleotide-binding pocket to fully close and dampens ATP hydrolysis; 3) 13 neck-linker residues are required to assume a stable docked conformation; 4) the neck-linker position controls the hydrolysis rather than the nucleotide binding step; 5) the two motor domains of KIF14 dimers adopt distinct conformations when bound to the microtubule; and 6) the formation of the two-heads-bound-state introduces structural changes in both motor domains of KIF14 dimers. These observations provide the structural basis for a coordinated chemo-mechanical kinesin translocation model.


  • Organizational Affiliation

    Department Physiology and Biophysics, Albert Einstein College of Medicine, New York, NY, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tubulin alpha-1B chainA,
D [auth E]
451Sus scrofaMutation(s): 0
EC: 3.6.5
UniProt
Find proteins for Q2XVP4 (Sus scrofa)
Explore Q2XVP4
Go to UniProtKB:  Q2XVP4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2XVP4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Tubulin beta-2B chainB,
E [auth I]
445Sus scrofaMutation(s): 0
UniProt
Find proteins for A0A287AZ37 (Sus scrofa)
Explore A0A287AZ37
Go to UniProtKB:  A0A287AZ37
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A287AZ37
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Kinesin-like protein KIF14C [auth K],
F [auth N]
370Mus musculusMutation(s): 0
Gene Names: Kif14
UniProt
Find proteins for L0N7N1 (Mus musculus)
Explore L0N7N1
Go to UniProtKB:  L0N7N1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupL0N7N1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TA1
Query on TA1

Download Ideal Coordinates CCD File
J [auth B],
P [auth I]
TAXOL
C47 H51 N O14
RCINICONZNJXQF-MZXODVADSA-N
GTP
Query on GTP

Download Ideal Coordinates CCD File
G [auth A],
M [auth E]
GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O14 P3
XKMLYUALXHKNFT-UUOKFMHZSA-N
ANP
Query on ANP

Download Ideal Coordinates CCD File
L [auth K],
Q [auth N]
PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER
C10 H17 N6 O12 P3
PVKSNHVPLWYQGJ-KQYNXXCUSA-N
GDP
Query on GDP

Download Ideal Coordinates CCD File
I [auth B],
O [auth I]
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
H [auth A],
K,
N [auth E]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM113164
Natural Sciences and Engineering Research Council (NSERC, Canada)CanadaRGPIN/04103-2015
Canadian Cancer Society Research InstituteCanada703405
Fonds de Recherche du Quebec-Sante (FRSQ)CanadaChercheure-Boursiere Junior 1, Junior 2 Awards
Canadian Institutes of Health Research (CIHR)CanadaNew Investigator Award
Simons FoundationUnited StatesSF349247
NYSTARUnited States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM103310
Agouron InstituteUnited StatesF00316
National Institutes of Health/Office of the DirectorUnited StatesOD019994

Revision History  (Full details and data files)

  • Version 1.0: 2021-05-05
    Type: Initial release
  • Version 1.1: 2021-07-07
    Changes: Author supporting evidence, Database references
  • Version 1.2: 2024-05-29
    Changes: Data collection, Database references
