6WUC

The yeast Ctf3 complex with Cnn1-Wip1


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.23 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

The Structural Basis for Kinetochore Stabilization by Cnn1/CENP-T.

Hinshaw, S.M.Harrison, S.C.

(2020) Curr Biol 30: 3425-3431.e3

  • DOI: https://doi.org/10.1016/j.cub.2020.06.024
  • Primary Citation of Related Structures:
    6WUC

  • PubMed Abstract:

    Chromosome segregation depends on a regulated connection between spindle microtubules and centromeric DNA. The kinetochore mediates this connection and ensures it persists during anaphase, when sister chromatids must transit into daughter cells uninterrupted. The Ctf19 complex (Ctf19c) forms the centromeric base of the kinetochore in budding yeast. Biochemical experiments show that Ctf19c members associate hierarchically when purified from cell extract [1], an observation that is mostly explained by the structure of the complex [2]. The Ctf3 complex (Ctf3c), which is not required for the assembly of most other Ctf19c factors, disobeys the biochemical assembly hierarchy when observed in dividing cells that lack more basal components [3]. Thus, the biochemical experiments do not completely recapitulate the logic of centromeric Ctf19c assembly. We now present a high-resolution structure of the Ctf3c bound to the Cnn1-Wip1 heterodimer. Associated live-cell imaging experiments provide a mechanism for Ctf3c and Cnn1-Wip1 recruitment to the kinetochore. The mechanism suggests feedback regulation of Ctf19c assembly and unanticipated similarities in kinetochore organization between yeast and vertebrates.


  • Organizational Affiliation

    Harvard Medical School, Howard Hughes Medical Institute, Boston, MA, USA. Electronic address: hinshaw@crystal.harvard.edu.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Inner kinetochore subunit MCM16A [auth H]184Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q12262 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12262
Go to UniProtKB:  Q12262
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12262
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Inner kinetochore subunit CTF3B [auth I]736Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q12748 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12748
Go to UniProtKB:  Q12748
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12748
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Inner kinetochore subunit MCM22C [auth K]242Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P47167 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47167
Go to UniProtKB:  P47167
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47167
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Inner kinetochore subunit WIP1D [auth W]92Saccharomyces cerevisiaeMutation(s): 0
Gene Names: WIP1
UniProt
Find proteins for Q2V2P8 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q2V2P8
Go to UniProtKB:  Q2V2P8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2V2P8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Inner kinetochore subunit CNN1E [auth T]361Saccharomyces cerevisiaeMutation(s): 0
Gene Names: CNN1
UniProt
Find proteins for P43618 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P43618
Go to UniProtKB:  P43618
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP43618
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.23 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Howard Hughes Medical Institute (HHMI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2020-06-17
    Type: Initial release
  • Version 1.1: 2020-12-30
    Changes: Database references
  • Version 1.2: 2024-03-06
    Changes: Data collection, Database references
