6W0S | pdb_00006w0s

Crystal structure of substrate free cytochrome P450 NasF5053 from Streptomyces sp. NRRL F-5053


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.220 (Depositor), 0.220 (DCC)
  • R-Value Work:
    0.186 (Depositor), 0.186 (DCC)
  • R-Value Observed:
    0.187 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6W0S

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Molecular basis of regio- and stereo-specificity in biosynthesis of bacterial heterodimeric diketopiperazines.

Sun, C.Luo, Z.Zhang, W.Tian, W.Peng, H.Lin, Z.Deng, Z.Kobe, B.Jia, X.Qu, X.

(2020) Nat Commun 11: 6251-6251

  • DOI: https://doi.org/10.1038/s41467-020-20022-5
  • Primary Citation Related Structures:
    6VXV, 6VZA, 6VZB, 6W0S

  • PubMed Abstract:

    Bacterial heterodimeric tryptophan-containing diketopiperazines (HTDKPs) are a growing family of bioactive natural products. They are challenging to prepare by chemical routes due to the polycyclic and densely functionalized backbone. Through functional characterization and investigation, we herein identify a family of three related HTDKP-forming cytochrome P450s (NasbB, Nas S1868 and Nas F5053 ) and reveal four critical residues (Qln65, Ala86, Ser284 and Val288) that control their regio- and stereo-selectivity to generate diverse dimeric DKP frameworks. Engineering these residues can alter the specificities of the enzymes to produce diverse frameworks. Determining the crystal structures (1.70-1.47 Å) of Nas F5053 (ligand-free and substrate-bound Nas F5053 and its Q65I-A86G and S284A-V288A mutants) and molecular dynamics simulation finally elucidate the specificity-conferring mechanism of these residues. Our results provide a clear molecular and mechanistic basis into this family of HTDKP-forming P450s, laying a solid foundation for rapid access to the molecular diversity of HTDKP frameworks through rational engineering of the P450s.


  • Organizational Affiliation
    • State Key Laboratory of Microbial Metabolism and School of Life Sciences and Biotechnology, Shanghai Jiao Tong University, 200240, Shanghai, China.

Macromolecule Content

  • Total Structure Weight: 88.82 kDa
  • Atom Count: 6,980
  • Modeled Residue Count: 793
  • Deposited Residue Count: 796
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
cytochrome P450-F5053
A, B
398Streptomyces sp. NRRL F-5053Mutation(s): 0
EC: 1.14
UniProt
Find proteins for A0A8I3B027 (Streptomyces sp. NRRL F-5053)
Explore A0A8I3B027
Go to UniProtKB:  A0A8I3B027
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A8I3B027
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEM
(Subject of Investigation/LOI)

Query on HEM



Download:Ideal Coordinates CCD File
K [auth A],
Q [auth B]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
C [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
BR

Query on BR



Download:Ideal Coordinates CCD File
D [auth A],
E [auth A],
L [auth B],
M [auth B]
BROMIDE ION
Br
CPELXLSAUQHCOX-UHFFFAOYSA-M
CL

Query on CL



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
H [auth A]
I [auth A]
N [auth B]
F [auth A],
G [auth A],
H [auth A],
I [auth A],
N [auth B],
O [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA

Query on NA



Download:Ideal Coordinates CCD File
J [auth A],
P [auth B]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.220 (Depositor), 0.220 (DCC)
  • R-Value Work:  0.186 (Depositor), 0.186 (DCC)
  • R-Value Observed: 0.187 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.208α = 90
b = 91.325β = 96.407
c = 98.275γ = 90
Software Package:
Software NamePurpose
PHENIXmodel building
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Health and Medical Research Council (NHMRC, Australia)Australia1071659
National Natural Science Foundation of China (NSFC)China31770063

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-11
    Type: Initial release
  • Version 1.1: 2020-12-23
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
