6VXY

Triazole bridged SFTI1 inhibitor in complex with beta-trypsin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.40 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.212
  • R-Value Observed: 0.214

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6VXY does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Application and Structural Analysis of Triazole-Bridged Disulfide Mimetics in Cyclic Peptides.

White, A.M.de Veer, S.J.Wu, G.Harvey, P.J.Yap, K.King, G.J.Swedberg, J.E.Wang, C.K.Law, R.H.P.Durek, T.Craik, D.J.

(2020) Angew Chem Int Ed Engl

  • DOI: https://doi.org/10.1002/anie.202003435
  • Primary Citation of Related Structures:
    6Q1U, 6U22, 6U24, 6U7Q, 6U7R, 6U7S, 6U7U, 6U7W, 6U7X, 6VXY, 6VY8

  • PubMed Abstract:

    Ruthenium-catalysed azide-alkyne cycloaddition (RuAAC) provides access to 1,5-disubstituted 1,2,3-triazole motifs in peptide engineering applications. However, investigation of this motif as a disulfide mimetic in cyclic peptides has been limited, and the structural consequences remain to be studied. We report synthetic strategies to install various triazole linkages into cyclic peptides through backbone cyclisation and RuAAC cross-linking reactions. These linkages were evaluated in four serine protease inhibitors based on sunflower trypsin inhibitor-1. NMR and X-ray crystallography revealed exceptional consensus of bridging distance and backbone conformations (RMSD<0.5 Å) of the triazole linkages compared to the parent disulfide molecules. The triazole-bridged peptides also displayed superior half-lives in liver S9 stability assays compared to disulfide-bridged peptides. This work establishes a foundation for the application of 1,5-disubstituted 1,2,3-triazoles as disulfide mimetics.


  • Organizational Affiliation

    ARC Centre of Excellence for Innovations in Peptide and Protein Science, Institute for Molecular Bioscience, The University of Queensland, Brisbane, QLD, 4072, Australia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cationic trypsin223Bos taurusMutation(s): 0
EC: 3.4.21.4
UniProt
Find proteins for P00760 (Bos taurus)
Explore P00760
Go to UniProtKB:  P00760
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00760
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
SFTI1 inhibitor GLY-ARG-GLY-THR-LYS-SER-ILE-PRO-PRO-ILE-ALA-PHE-PRO-ASPB [auth C]14Helianthus annuusMutation(s): 0
UniProt
Find proteins for Q4GWU5 (Helianthus annuus)
Explore Q4GWU5
Go to UniProtKB:  Q4GWU5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4GWU5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
WMH (Subject of Investigation/LOI)
Query on WMH

Download Ideal Coordinates CCD File
D [auth C]1-methyl-1H-1,2,3-triazole
C3 H5 N3
JWAWEQBUZOGIBZ-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
C [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Biologically Interesting Molecules (External Reference) 1 Unique
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.40 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.212
  • R-Value Observed: 0.214
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.319α = 90
b = 64.861β = 90
c = 70.149γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report

Currently 6VXY does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Australian Research Council (ARC)AustraliaDP150100443

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-01
    Type: Initial release
  • Version 1.1: 2023-10-11
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.2: 2024-10-23
    Changes: Structure summary
