6VSX | pdb_00006vsx

X-ray crystal structure of the C-terminal domain of Bacillus subtilis RNA polymerase binding helicase HelD


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.202 (Depositor), 0.198 (DCC)
  • R-Value Work:
    0.172 (Depositor), 0.172 (DCC)
  • R-Value Observed:
    0.175 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6VSX

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Mycobacterial HelD is a nucleic acids-clearing factor for RNA polymerase.

Kouba, T.Koval', T.Sudzinova, P.Pospisil, J.Brezovska, B.Hnilicova, J.Sanderova, H.Janouskova, M.Sikova, M.Halada, P.Sykora, M.Barvik, I.Novacek, J.Trundova, M.Duskova, J.Skalova, T.Chon, U.Murakami, K.S.Dohnalek, J.Krasny, L.

(2020) Nat Commun 11: 6419-6419

  • DOI: https://doi.org/10.1038/s41467-020-20158-4
  • Primary Citation Related Structures:
    6VSX, 6YXU, 6YYS

  • PubMed Abstract:

    RNA synthesis is central to life, and RNA polymerase (RNAP) depends on accessory factors for recovery from stalled states and adaptation to environmental changes. Here, we investigated the mechanism by which a helicase-like factor HelD recycles RNAP. We report a cryo-EM structure of a complex between the Mycobacterium smegmatis RNAP and HelD. The crescent-shaped HelD simultaneously penetrates deep into two RNAP channels that are responsible for nucleic acids binding and substrate delivery to the active site, thereby locking RNAP in an inactive state. We show that HelD prevents non-specific interactions between RNAP and DNA and dissociates stalled transcription elongation complexes. The liberated RNAP can either stay dormant, sequestered by HelD, or upon HelD release, restart transcription. Our results provide insights into the architecture and regulation of the highly medically-relevant mycobacterial transcription machinery and define HelD as a clearing factor that releases RNAP from nonfunctional complexes with nucleic acids.


  • Organizational Affiliation
    • EMBL Grenoble, 71 Avenue des Martyrs, Grenoble, France. tkouba@embl.fr.

Macromolecule Content

  • Total Structure Weight: 21.38 kDa
  • Atom Count: 1,382
  • Modeled Residue Count: 159
  • Deposited Residue Count: 188
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA helicase188Bacillus subtilisMutation(s): 0
Gene Names: B4417_3167
EC: 3.6.4.12 (PDB Primary Data), 3.6.4 (UniProt)
UniProt
Find proteins for O32215 (Bacillus subtilis (strain 168))
Explore O32215
Go to UniProtKB:  O32215
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO32215
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PO4
(Subject of Investigation/LOI)

Query on PO4



Download:Ideal Coordinates CCD File
B [auth A]PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.202 (Depositor), 0.198 (DCC)
  • R-Value Work:  0.172 (Depositor), 0.172 (DCC)
  • R-Value Observed: 0.175 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 106.963α = 90
b = 38.813β = 101.448
c = 44.427γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing
PHENIXmodel building

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM131860

Revision History  (Full details and data files)

  • Version 1.0: 2020-06-10
    Type: Initial release
  • Version 1.1: 2021-01-13
    Changes: Database references
  • Version 1.2: 2024-03-06
    Changes: Data collection, Database references
