6VOW | pdb_00006vow

Crystal structure of multi-copper oxidase from Pseudomonas Thermotolerans

• PDB DOI: https://doi.org/10.2210/pdb6VOW/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Zestomonas thermotolerans
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2020-01-31 Released: 2021-02-03
• Deposition Author(s): Coler, E.A., Soares, A.S., Collins, R.E.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), Department of Energy (DOE, United States)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.92 Å
• R-Value Free:
  0.232 (Depositor), 0.235 (DCC)
• R-Value Work:
  0.163 (Depositor), 0.171 (DCC)
• R-Value Observed:
  0.166 (Depositor)

Starting Model: experimental

Literature

Crystal structure of multi-copper oxidase from Pseudomonas Thermotolerans

Coler, E.A., Soares, A.S., Collins, R.E.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 51.09 kDa
• Atom Count: 3,419
• Modeled Residue Count: 409
• Deposited Residue Count: 456
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
multicopper oxidase	A	456	Zestomonas thermotolerans	Mutation(s): 0
UniProt
Find proteins for A0A8I3B022 (Zestomonas thermotolerans) Explore A0A8I3B022  Go to UniProtKB:  A0A8I3B022

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
C2O (Subject of Investigation/LOI)	B [auth A]	CU-O-CU LINKAGE Cu2 O BERDEBHAJNAUOM-UHFFFAOYSA-N
CU	C [auth A], D [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.92 Å
• R-Value Free:  0.232 (Depositor), 0.235 (DCC)
• R-Value Work:  0.163 (Depositor), 0.171 (DCC)
• R-Value Observed: 0.166 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 135.11	α = 90
b = 68.84	β = 93.05
c = 49.52	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2021-02-03
Deposition Author(s): Coler, E.A., Soares, A.S., Collins, R.E.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P41GM111244
Department of Energy (DOE, United States)	United States	KP1605010
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	1R21GM129570-01

Revision History

• Version 1.0: 2021-02-03
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Data collection, Database references, Refinement description
