6VN3

USP7 IN COMPLEX WITH LIGAND COMPOUND 23


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.73 Å
  • R-Value Free: 0.290
  • R-Value Work: 0.222
  • R-Value Observed: 0.225

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.1 of the entry. See complete history


Literature

Discovery of Potent, Selective, and Orally Bioavailable Inhibitors of USP7 with In Vivo Antitumor Activity.

Leger, P.R.Hu, D.X.Biannic, B.Bui, M.Han, X.Karbarz, E.Maung, J.Okano, A.Osipov, M.Shibuya, G.M.Young, K.Higgs, C.Abraham, B.Bradford, D.Cho, C.Colas, C.Jacobson, S.Ohol, Y.M.Pookot, D.Rana, P.Sanchez, J.Shah, N.Sun, M.Wong, S.Brockstedt, D.G.Kassner, P.D.Schwarz, J.B.Wustrow, D.J.

(2020) J Med Chem 63: 5398-5420

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c00245
  • Primary Citation of Related Structures:
    6VN2, 6VN3, 6VN4, 6VN5, 6VN6

  • PubMed Abstract:

    USP7 is a promising target for cancer therapy as its inhibition is expected to decrease function of oncogenes, increase tumor suppressor function, and enhance immune function. Using a structure-based drug design strategy, a new class of reversible USP7 inhibitors has been identified that is highly potent in biochemical and cellular assays and extremely selective for USP7 over other deubiquitinases. The succinimide was identified as a key potency-driving motif, forming two strong hydrogen bonds to the allosteric pocket of USP7. Redesign of an initial benzofuran-amide scaffold yielded a simplified ether series of inhibitors, utilizing acyclic conformational control to achieve proper amine placement. Further improvements were realized upon replacing the ether-linked amines with carbon-linked morpholines, a modification motivated by free energy perturbation (FEP+) calculations. This led to the discovery of compound 41 , a highly potent, selective, and orally bioavailable USP7 inhibitor. In xenograft studies, compound 41 demonstrated tumor growth inhibition in both p53 wildtype and p53 mutant cancer cell lines, demonstrating that USP7 inhibitors can suppress tumor growth through multiple different pathways.


  • Organizational Affiliation

    RAPT Therapeutics, Inc., 561 Eccles Avenue, South San Francisco, California 94080, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ubiquitin carboxyl-terminal hydrolase 7
A, B
350Homo sapiensMutation(s): 0
Gene Names: USP7HAUSP
EC: 3.4.19.12
UniProt & NIH Common Fund Data Resources
Find proteins for Q93009 (Homo sapiens)
Explore Q93009
Go to UniProtKB:  Q93009
PHAROS:  Q93009
GTEx:  ENSG00000187555
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93009
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
R3Y (Subject of Investigation/LOI)
Query on R3Y

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
1-{[7-(5-chloro-2-{[(3R,4S)-4-fluoropyrrolidin-3-yl]oxy}-3-methylphenyl)thieno[3,2-b]pyridin-2-yl]methyl}-1H-pyrrole-2,5-dione
C23 H21 Cl F N3 O3 S
SWLBIOVQZDSJKD-PKOBYXMFSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
R3Y BindingDB:  6VN3 IC50: 1.2 (nM) from 1 assay(s)
EC50: 560 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.73 Å
  • R-Value Free: 0.290
  • R-Value Work: 0.222
  • R-Value Observed: 0.225
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.51α = 90
b = 65.834β = 94.62
c = 85.077γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-29
    Type: Initial release
  • Version 1.1: 2020-06-10
    Changes: Database references
  • Version 2.0: 2020-06-17
    Changes: Non-polymer description, Refinement description, Structure summary
  • Version 2.1: 2024-10-30
    Changes: Advisory, Data collection, Database references, Refinement description, Structure summary
