6VFW

Crystal structure of human delta protocadherin 10 EC1-EC4

  • Classification: CELL ADHESION
  • Organism(s): Homo sapiens
  • Expression System: Homo sapiens
  • Mutation(s): No

  • Deposited: 2020-01-06 Released: 2020-03-11
  • Deposition Author(s): Harrison, O.J., Brasch, J., Shapiro, L.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Science Foundation (NSF, United States)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.60 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.277
  • R-Value Observed: 0.277

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6VFW does not have a validation slider image.


This is version 2.2 of the entry. See complete history


Literature

Family-wide Structural and Biophysical Analysis of Binding Interactions among Non-clustered delta-Protocadherins.

Harrison, O.J.Brasch, J.Katsamba, P.S.Ahlsen, G.Noble, A.J.Dan, H.Sampogna, R.V.Potter, C.S.Carragher, B.Honig, B.Shapiro, L.

(2020) Cell Rep 30: 2655-2671.e7

  • DOI: https://doi.org/10.1016/j.celrep.2020.02.003
  • Primary Citation of Related Structures:
    6VFP, 6VFQ, 6VFR, 6VFT, 6VFU, 6VFV, 6VFW, 6VG1, 6VG4

  • PubMed Abstract:

    Non-clustered δ1- and δ2-protocadherins, close relatives of clustered protocadherins, function in cell adhesion and motility and play essential roles in neural patterning. To understand the molecular interactions underlying these functions, we used solution biophysics to characterize binding of δ1- and δ2-protocadherins, determined crystal structures of ectodomain complexes from each family, and assessed ectodomain assembly in reconstituted intermembrane junctions by cryoelectron tomography (cryo-ET). Homophilic trans (cell-cell) interactions were preferred for all δ-protocadherins, with additional weaker heterophilic interactions observed exclusively within each subfamily. As expected, δ1- and δ2-protocadherin trans dimers formed through antiparallel EC1-EC4 interfaces, like clustered protocadherins. However, no ectodomain-mediated cis (same-cell) interactions were detectable in solution; consistent with this, cryo-ET of reconstituted junctions revealed dense assemblies lacking the characteristic order observed for clustered protocadherins. Our results define non-clustered protocadherin binding properties and their structural basis, providing a foundation for interpreting their functional roles in neural patterning.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protocadherin-10
A, B, C, D, E
444Homo sapiensMutation(s): 0
Gene Names: PCDH10KIAA1400
UniProt & NIH Common Fund Data Resources
Find proteins for Q9P2E7 (Homo sapiens)
Explore Q9P2E7
Go to UniProtKB:  Q9P2E7
PHAROS:  Q9P2E7
GTEx:  ENSG00000138650
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9P2E7
Glycosylation
Glycosylation Sites: 3Go to GlyGen: Q9P2E7-1
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose
F, G, H, I, J
6N-Glycosylation
Glycosylation Resources
GlyTouCan:  G82348BZ
GlyCosmos:  G82348BZ
GlyGen:  G82348BZ
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MAN
Query on MAN

Download Ideal Coordinates CCD File
AB [auth D]
BB [auth D]
EA [auth B]
FA [auth B]
LB [auth E]
AB [auth D],
BB [auth D],
EA [auth B],
FA [auth B],
LB [auth E],
MB [auth E],
PA [auth C],
QA [auth C],
T [auth A],
U [auth A]
alpha-D-mannopyranose
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
CA [auth B]
CB [auth E]
DA [auth B]
AA [auth B],
BA [auth B],
CA [auth B],
CB [auth E],
DA [auth B],
DB [auth E],
EB [auth E],
FB [auth E],
GA [auth C],
GB [auth E],
HA [auth C],
HB [auth E],
IA [auth C],
IB [auth E],
JA [auth C],
JB [auth E],
K [auth A],
KA [auth C],
KB [auth E],
L [auth A],
LA [auth C],
M [auth A],
MA [auth C],
N [auth A],
NA [auth C],
O [auth A],
OA [auth C],
P [auth A],
Q [auth A],
R [auth A],
RA [auth D],
S [auth A],
SA [auth D],
TA [auth D],
UA [auth D],
V [auth B],
VA [auth D],
W [auth B],
WA [auth D],
X [auth B],
XA [auth D],
Y [auth B],
YA [auth D],
Z [auth B],
ZA [auth D]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.60 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.277
  • R-Value Observed: 0.277
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 346.55α = 90
b = 73.193β = 132.057
c = 246.328γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report

Currently 6VFW does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01MH114817
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM118584
National Science Foundation (NSF, United States)United StatesMCB-1412472

Revision History  (Full details and data files)

  • Version 1.0: 2020-03-11
    Type: Initial release
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Refinement description, Structure summary
  • Version 2.1: 2023-10-11
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
  • Version 2.2: 2024-10-23
    Changes: Structure summary
