6VBD | pdb_00006vbd

Crystal structure of transpeptidase domain of PBP2 from Neisseria gonorrhoeae cephalosporin-resistant strain H041 acylated by ceftriaxone

PDB DOI: https://doi.org/10.2210/pdb6VBD/pdb

Classification: HYDROLASE/ANTIBIOTIC
Organism(s): Neisseria gonorrhoeae
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2019-12-18 Released: 2020-04-15
Deposition Author(s): Singh, A., Davies, C.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.195 (Depositor), 0.203 (DCC)
R-Value Work:
0.171 (Depositor), 0.182 (DCC)
R-Value Observed:
0.172 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6VBD

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Mutations in Neisseria gonorrhoeae penicillin-binding protein 2 associated with extended-spectrum cephalosporin resistance create an energetic barrier against acylation via restriction of protein dynamics

Singh, A., Turner, J., Tomberg, J., Fedarovich, A., Unemo, M., Nicholas, R.A., Davies, C.

(2020) J Biological Chem

Macromolecule Content

Total Structure Weight: 35.85 kDa
Atom Count: 2,649
Modeled Residue Count: 324
Deposited Residue Count: 330
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable peptidoglycan D,D-transpeptidase PenA	A	330	Neisseria gonorrhoeae	Mutation(s): 0 Gene Names: penA EC: 3.4.16.4
UniProt
Find proteins for F2Z7K9 (Neisseria gonorrhoeae) Explore F2Z7K9 Go to UniProtKB: F2Z7K9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	F2Z7K9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CEF Query on CEF Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CEFOTAXIME, C3' cleaved, open, bound form C₁₄ H₁₅ N₅ O₅ S₂ NRYMPLKBKFIWQC-YVCCLBOHSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.195 (Depositor), 0.203 (DCC)
R-Value Work: 0.171 (Depositor), 0.182 (DCC)
R-Value Observed: 0.172 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.311	α = 90
b = 60.682	β = 90
c = 109.344	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
FFT	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-04-15

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM066861

Revision History (Full details and data files)

Version 1.0: 2020-04-15
Type: Initial release
Version 1.1: 2024-11-06
Changes: Data collection, Database references, Structure summary
