6UJK | pdb_00006ujk

Crystal Structure of a Probable short-chain type dehydrogenase/reductase (Rv1144) from Mycobacterium tuberculosis with bound NAD

PDB DOI: https://doi.org/10.2210/pdb6UJK/pdb

Classification: OXIDOREDUCTASE
Organism(s): Mycobacterium tuberculosis H37Rv
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2019-10-03 Released: 2019-10-16
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.20 Å
R-Value Free:
0.137 (Depositor), 0.137 (DCC)
R-Value Work:
0.122 (Depositor), 0.123 (DCC)
R-Value Observed:
0.122 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of a Probable short-chain type dehydrogenase/reductase (Rv1144) from Mycobacterium tuberculosis with bound NAD

Dranow, D.M., Abendroth, J., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 55.58 kDa
Atom Count: 4,280
Modeled Residue Count: 489
Deposited Residue Count: 516
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized oxidoreductase Rv1144	A, B	258	Mycobacterium tuberculosis H37Rv	Mutation(s): 0 Gene Names: Rv1144 EC: 1
UniProt
Find proteins for P9WGQ7 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WGQ7 Go to UniProtKB: P9WGQ7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WGQ7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD (Subject of Investigation/LOI) Query on NAD Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain H [auth B] MOL2 format, chain C [auth A] MOL2 format, chain H [auth B] mmCIF format, chain C [auth A] mmCIF format, chain H [auth B]	C [auth A], H [auth B]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain C [auth A] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain H [auth B]
TRS Query on TRS Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain I [auth B] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain J [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain I [auth B] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain J [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain I [auth B] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain J [auth B]	D [auth A] E [auth A] F [auth A] I [auth B] J [auth B] D [auth A], E [auth A], F [auth A], I [auth B], J [auth B], K [auth B], L [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B]
