6U11 | pdb_00006u11

Xenopus laevis N-acetylglucosamine-1-phosphodiester alpha-N-acetylglucosaminidase (NAGPA) (C46S C219S C453S C480S C486S) with CTD mostly flexible

• PDB DOI: https://doi.org/10.2210/pdb6U11/pdb

• Classification: HYDROLASE
• Organism(s): Xenopus laevis
• Expression System: Spodoptera frugiperda
• Mutation(s): Yes


• Deposited: 2019-08-15 Released: 2020-02-19
• Deposition Author(s): Gorelik, A., Illes, K., Nagar, B.
• Funding Organization(s): Canadian Institutes of Health Research (CIHR)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.70 Å
• R-Value Free:
  0.225 (Depositor), 0.226 (DCC)
• R-Value Work:
  0.196 (Depositor), 0.196 (DCC)
• R-Value Observed:
  0.199 (Depositor)

Starting Model: experimental

Literature

Crystal Structure of the Mannose-6-Phosphate Uncovering Enzyme.

Gorelik, A., Illes, K., Nagar, B.

(2020) Structure 28: 426-436.e3

• PubMed: 32109365
• DOI: https://doi.org/10.1016/j.str.2020.02.001
• Primary Citation Related Structures:
  6PKG, 6PKH, 6PKI, 6PKU, 6PKY, 6U11


• PubMed Abstract:


  Most lysosomal hydrolytic enzymes reach their destination via the mannose-6-phosphate (M6P) pathway. The enzyme N-acetylglucosamine-1-phosphodiester α-N-acetylglucosaminidase (NAGPA, or "uncovering enzyme") catalyzes the second step in the M6P tag formation, namely the removal of the masking N-acetylglucosamine (GlcNAc) portion. Defects in this protein are associated with non-syndromic stuttering. To gain a better understanding of the function and regulation of this enzyme, we determined its crystal structure. The propeptide binds in a groove on the globular catalytic domain, blocking active site access. High-affinity substrate binding is enabled by a conformational switch in an active site loop. The protein recognizes the GlcNAc and phosphate portions of its substrate, but not the mannose moiety of the glycan. Based on enzymatic and ¹ H-NMR analysis, a catalytic mechanism is proposed. Crystallographic and solution scattering analyses suggest that the C-terminal domain forms a long flexible stem that extends the enzyme away from the Golgi membrane.

---

Organizational Affiliation:
• Department of Biochemistry, McGill University, Room 464, 3649 Promenade Sir-William-Osler, Montreal, QC H3G 0B1, Canada.
Department of Biochemistry, McGill University, Room 464, 3649 Promenade Sir-William-Osler, Montreal, QC H3G 0B1, Canada. Electronic address: [e-mail].

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 55.91 kDa
• Atom Count: 2,683
• Modeled Residue Count: 316
• Deposited Residue Count: 497
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
EGF-like domain-containing protein	A	497	Xenopus laevis	Mutation(s): 7  Gene Names: XELAEV_18011890mg
UniProt
Find proteins for A0A1L8HDP6 (Xenopus laevis) Explore A0A1L8HDP6  Go to UniProtKB:  A0A1L8HDP6
Glycosylation
Glycosylation Sites: 3

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose	B	3		N-Glycosylation
Glycosylation Resources
GlyTouCan: G21290RB GlyCosmos: G21290RB GlyGen: G21290RB

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C	2		N-Glycosylation
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	D [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N
K	E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.70 Å
• R-Value Free:  0.225 (Depositor), 0.226 (DCC)
• R-Value Work:  0.196 (Depositor), 0.196 (DCC)
• R-Value Observed: 0.199 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.019	α = 90
b = 383.969	β = 90
c = 96.767	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2020-02-19
Deposition Author(s): Gorelik, A., Illes, K., Nagar, B.

---

Funding Organization	Location	Grant Number
Canadian Institutes of Health Research (CIHR)	Canada	MOP-133535

Revision History

• Version 1.0: 2020-02-19
  Type: Initial release

• Version 1.1: 2020-03-11
  Changes: Database references
• Version 1.2: 2020-04-15
  Changes: Database references
• Version 2.0: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
• Version 2.1: 2023-10-11
  Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
• Version 2.2: 2024-10-23
  Changes: Structure summary
