6TNY

Processive human polymerase delta holoenzyme


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.08 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of the processive human Pol delta holoenzyme.

Lancey, C.Tehseen, M.Raducanu, V.S.Rashid, F.Merino, N.Ragan, T.J.Savva, C.G.Zaher, M.S.Shirbini, A.Blanco, F.J.Hamdan, S.M.De Biasio, A.

(2020) Nat Commun 11: 1109-1109

  • DOI: https://doi.org/10.1038/s41467-020-14898-6
  • Primary Citation of Related Structures:
    6S1M, 6S1N, 6S1O, 6TNY, 6TNZ

  • PubMed Abstract:

    In eukaryotes, DNA polymerase δ (Pol δ) bound to the proliferating cell nuclear antigen (PCNA) replicates the lagging strand and cooperates with flap endonuclease 1 (FEN1) to process the Okazaki fragments for their ligation. We present the high-resolution cryo-EM structure of the human processive Pol δ-DNA-PCNA complex in the absence and presence of FEN1. Pol δ is anchored to one of the three PCNA monomers through the C-terminal domain of the catalytic subunit. The catalytic core sits on top of PCNA in an open configuration while the regulatory subunits project laterally. This arrangement allows PCNA to thread and stabilize the DNA exiting the catalytic cleft and recruit FEN1 to one unoccupied monomer in a toolbelt fashion. Alternative holoenzyme conformations reveal important functional interactions that maintain PCNA orientation during synthesis. This work sheds light on the structural basis of Pol δ's activity in replicating the human genome.


  • Organizational Affiliation

    Leicester Institute of Structural & Chemical Biology and Department of Molecular & Cell Biology, University of Leicester, Lancaster Rd, Leicester, LE1 7HB, UK.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase delta catalytic subunit1,107Homo sapiensMutation(s): 0
Gene Names: POLD1POLD
EC: 2.7.7.7 (PDB Primary Data), 3.1.11 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P28340 (Homo sapiens)
Explore P28340
Go to UniProtKB:  P28340
PHAROS:  P28340
GTEx:  ENSG00000062822
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28340
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase delta subunit 2469Homo sapiensMutation(s): 0
Gene Names: POLD2
UniProt & NIH Common Fund Data Resources
Find proteins for P49005 (Homo sapiens)
Explore P49005
Go to UniProtKB:  P49005
PHAROS:  P49005
GTEx:  ENSG00000106628
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49005
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase delta subunit 3474Homo sapiensMutation(s): 0
Gene Names: POLD3KIAA0039
UniProt & NIH Common Fund Data Resources
Find proteins for Q15054 (Homo sapiens)
Explore Q15054
Go to UniProtKB:  Q15054
PHAROS:  Q15054
GTEx:  ENSG00000077514
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15054
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase delta subunit 4137Homo sapiensMutation(s): 0
Gene Names: POLD4POLDS
UniProt & NIH Common Fund Data Resources
Find proteins for Q9HCU8 (Homo sapiens)
Explore Q9HCU8
Go to UniProtKB:  Q9HCU8
GTEx:  ENSG00000175482
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HCU8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Proliferating cell nuclear antigen
E, F, G
264Homo sapiensMutation(s): 0
Gene Names: PCNA
UniProt & NIH Common Fund Data Resources
Find proteins for P12004 (Homo sapiens)
Explore P12004
Go to UniProtKB:  P12004
PHAROS:  P12004
GTEx:  ENSG00000132646
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP12004
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 6
MoleculeChains LengthOrganismImage
DNA primerH [auth P]25synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains LengthOrganismImage
DNA templateI [auth T]38synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.08 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2019-12-18
    Type: Initial release
  • Version 1.1: 2020-03-11
    Changes: Database references
  • Version 1.2: 2024-05-22
    Changes: Data collection, Database references, Derived calculations
