6R2D

Crystal structure of the SucA domain of Mycobacterium smegmatis KGD after soaking with succinylphosphonate phosphonoethyl ester, followed by temperature increase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.217
  • R-Value Observed: 0.219

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Conformational transitions in the active site of mycobacterial 2-oxoglutarate dehydrogenase upon binding phosphonate analogues of 2-oxoglutarate: From a Michaelis-like complex to ThDP adducts.

Wagner, T.Boyko, A.Alzari, P.M.Bunik, V.I.Bellinzoni, M.

(2019) J Struct Biol 208: 182-190

  • DOI: https://doi.org/10.1016/j.jsb.2019.08.012
  • Primary Citation of Related Structures:
    6R29, 6R2A, 6R2B, 6R2C, 6R2D

  • PubMed Abstract:

    Mycobacterial KGD, the thiamine diphosphate (ThDP)-dependent E1o component of the 2-oxoglutarate dehydrogenase complex (OGDHC), is known to undergo significant conformational changes during catalysis with two distinct conformational states, previously named as the early and late state. In this work, we employ two phosphonate analogues of 2-oxoglutarate (OG), i.e. succinyl phosphonate (SP) and phosphono ethyl succinyl phosphonate (PESP), as tools to isolate the first catalytic steps and understand the significance of conformational transitions for the enzyme regulation. The kinetics showed a more efficient inhibition of mycobacterial E1o by SP (K i 0.043 ± 0.013 mM) than PESP (K i 0.88 ± 0.28 mM), consistent with the different circular dichroism spectra of the corresponding complexes. PESP allowed us to get crystallographic snapshots of the Michaelis-like complex, the first one for 2-oxo acid dehydrogenases, followed by the covalent adduction of the inhibitor to ThDP, mimicking the pre-decarboxylation complex. In addition, covalent ThDP-phosphonate complexes obtained with both compounds by co-crystallization were in the late conformational state, probably corresponding to slowly dissociating enzyme-inhibitor complexes. We discuss the relevance of these findings in terms of regulatory features of the mycobacterial E1o enzymes, and in the perspective of developing tools for species-specific metabolic regulation.


  • Organizational Affiliation

    Unité de Microbiologie Structurale, Institut Pasteur, CNRS, Université de Paris, F-75724 Paris, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Multifunctional 2-oxoglutarate metabolism enzyme
A, B, C, D
868Mycolicibacterium smegmatis MC2 155Mutation(s): 0
Gene Names: kgdsucAMSMEG_5049MSMEI_4922
EC: 2.2.1.5 (PDB Primary Data), 4.1.1.71 (PDB Primary Data), 1.2.4.2 (PDB Primary Data), 2.3.1.61 (PDB Primary Data)
UniProt
Find proteins for A0R2B1 (Mycolicibacterium smegmatis (strain ATCC 700084 / mc(2)155))
Explore A0R2B1
Go to UniProtKB:  A0R2B1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0R2B1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZP1
Query on ZP1

Download Ideal Coordinates CCD File
E [auth A],
H [auth B],
K [auth C],
N [auth D]
(4~{S})-4-[(2~{R})-3-[(4-azanyl-2-methyl-pyrimidin-5-yl)methyl]-4-methyl-5-[2-[oxidanyl(phosphonooxy)phosphoryl]oxyethyl]-2~{H}-1,3-thiazol-2-yl]-4-[ethoxy(oxidanyl)phosphoryl]-4-oxidanyl-butanoic acid
C18 H31 N4 O13 P3 S
XUQXUYTXDQCESE-MSOLQXFVSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
G [auth A],
J [auth B],
M [auth C],
P [auth D]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
F [auth A],
I [auth B],
L [auth C],
O [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.217
  • R-Value Observed: 0.219
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.84α = 99.52
b = 83.73β = 98.94
c = 160.57γ = 100.81
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
autoPROCdata scaling
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-09-11
    Type: Initial release
  • Version 1.1: 2019-11-06
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Derived calculations, Refinement description
