6ODL | pdb_00006odl

Crystal structure of GluN2A agonist binding domain with 4-butyl-(S)-CCG-IV


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.283 (Depositor), 0.281 (DCC)
  • R-Value Work:
    0.224 (Depositor), 0.224 (DCC)
  • R-Value Observed:
    0.229 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6ODL

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Stereoselective synthesis of novel 2'-(S)-CCG-IV analogues as potent NMDA receptor agonists.

Maolanon, A.Papangelis, A.Kawiecki, D.Mou, T.C.Syrenne, J.T.Yi, F.Hansen, K.B.Clausen, R.P.

(2021) Eur J Med Chem 212: 113099-113099

  • DOI: https://doi.org/10.1016/j.ejmech.2020.113099
  • Primary Citation Related Structures:
    6ODL

  • PubMed Abstract:

    We developed a versatile stereoselective route for the synthesis of new 2'-(S)-CCG-IV analogues. The route allows for late stage diversification and thereby provides access to a great variety of conformationally restricted cyclopropyl glutamate analogues. A selection of the 2'-(S)-CCG-IV analogues were evaluated using two-electrode voltage-clamp electrophysiology at recombinant GluN1/GluN2A-D receptors, demonstrating that agonists can be developed with GluN2 subunit-dependent potency and agonist efficacy. We also describe a crystal structure of the GluN2A agonist binding domain in complex with 2'-butyl-(S)-CCG-IV that determines the position of 2'-substituents in (S)-CCG-IV agonists in the glutamate binding site and provides further insight to the structural determinants of their agonist efficacy. The stereoselective synthesis described here enables versatile and straight-forward modifications to diverse analogues of interest for the development of potent subtype-specific NMDA receptor agonists and other applications.


  • Organizational Affiliation
    • Department of Drug Design and Pharmacology, Faculty of Health and Medical Sciences, University of Copenhagen, DK, 2100, Copenhagen, Denmark.

Macromolecule Content

  • Total Structure Weight: 63.14 kDa
  • Atom Count: 4,596
  • Modeled Residue Count: 557
  • Deposited Residue Count: 558
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Glutamate receptor ionotropic, NMDA 2A,Glutamate receptor ionotropic, NMDA 2A
A, B
279Rattus norvegicusMutation(s): 0
Gene Names: Grin2a
UniProt
Find proteins for Q00959 (Rattus norvegicus)
Explore Q00959
Go to UniProtKB:  Q00959
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ00959
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Binding Affinity Annotations
IDSourceBinding Affinity
M7V BindingDB:  6ODL EC50: 2.88e+4 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.283 (Depositor), 0.281 (DCC)
  • R-Value Work:  0.224 (Depositor), 0.224 (DCC)
  • R-Value Observed: 0.229 (Depositor)
Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 52.094α = 90
b = 52.094β = 90
c = 197.804γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP20GM103546
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)United States1R01NS097536

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-01
    Type: Initial release
  • Version 1.1: 2021-02-24
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-10-30
    Changes: Structure summary
