6OCO

HUMAN PI3KDELTA IN COMPLEX WITH COMPOUND 6


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.58 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.259
  • R-Value Observed: 0.260

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Discovery and optimization of heteroaryl piperazines as potent and selective PI3K delta inhibitors.

Zhou, H.McGowan, M.A.Lipford, K.Christopher, M.Fradera, X.Witter, D.Lesburg, C.A.Li, C.Methot, J.L.Lampe, J.Achab, A.Shaffer, L.Goldenblatt, P.Shah, S.Bass, A.Schroeder, G.Chen, D.Zeng, H.Augustin, M.A.Katz, J.D.

(2020) Bioorg Med Chem Lett 30: 126715-126715

  • DOI: https://doi.org/10.1016/j.bmcl.2019.126715
  • Primary Citation of Related Structures:
    6OCO, 6OCU

  • PubMed Abstract:

    A high-throughput screening (HTS) campaign identified a class of heteroaryl piperazines with excellent baseline affinity and selectivity for phosphoinositide 3-kinase δ (PI3Kδ) over closely related isoforms. Rapid evaluation and optimization of structure-activity relationships (SAR) for this class, leveraging the modular nature of this scaffold, facilitated development of this hit class into a series of potent and selective inhibitors of PI3Kδ. This effort culminated in the identification of 29, which displayed excellent potency in enzyme and cell-based assays, as well as favorable pharmacokinetic and off-target profiles.


  • Organizational Affiliation

    Department of Discovery Chemistry, Merck & Co., Inc., 33 Avenue Louis Pasteur, Boston, MA 02115, USA. Electronic address: hua_zhou2@merck.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Phosphatidylinositol 4,5-bisphosphate 3-kinase catalytic subunit delta isoform1,015Homo sapiensMutation(s): 0
Gene Names: PIK3CD
EC: 2.7.1.153 (PDB Primary Data), 2.7.1.137 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for O00329 (Homo sapiens)
Explore O00329
Go to UniProtKB:  O00329
PHAROS:  O00329
GTEx:  ENSG00000171608
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO00329
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Phosphatidylinositol 3-kinase regulatory subunit alpha170Bos taurusMutation(s): 0
Gene Names: PIK3R1
UniProt
Find proteins for P23727 (Bos taurus)
Explore P23727
Go to UniProtKB:  P23727
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23727
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
M5V (Subject of Investigation/LOI)
Query on M5V

Download Ideal Coordinates CCD File
C [auth A]4-[(1S,4S)-5-(3-chlorophenyl)-2,5-diazabicyclo[2.2.1]heptan-2-yl]-2-(pyridin-3-yl)pyrimidine-5-carbonitrile
C21 H17 Cl N6
LYMCCCUAFBZMES-OALUTQOASA-N
Binding Affinity Annotations
IDSourceBinding Affinity
M5V BindingDB:  6OCO IC50: 474 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.58 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.259
  • R-Value Observed: 0.260
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.017α = 90
b = 108.981β = 90
c = 142.394γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XSCALEdata scaling
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-12-11
    Type: Initial release
  • Version 1.1: 2019-12-18
    Changes: Database references
  • Version 1.2: 2024-03-13
    Changes: Advisory, Data collection, Database references
