6NZX | pdb_00006nzx

Hadesarchaea YNP_N21 cytochrome b5 domain protein (KUO41884.1)

PDB DOI: https://doi.org/10.2210/pdb6NZX/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Hadesarchaea archaeon YNP_N21
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-02-14 Released: 2019-03-06
Deposition Author(s): Teakel, S.L., Marama, M.S., Aragao, D., Forwood, J.K., Cahill, M.A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.261 (Depositor), 0.266 (DCC)
R-Value Work:
0.221 (Depositor), 0.229 (DCC)
R-Value Observed:
0.223 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6NZX

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Hadesarchaea YNP_N21 cytochrome b5 domain protein (KUO41884.1)

Teakel, S.L., Marama, M.S., Aragao, D., Forwood, J.K., Cahill, M.A.

To be published.

Macromolecule Content

Total Structure Weight: 9.24 kDa
Atom Count: 663
Modeled Residue Count: 76
Deposited Residue Count: 78
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome B5	A	78	Hadesarchaea archaeon YNP_N21	Mutation(s): 0 Gene Names: APU95_03975
UniProt
Find proteins for A0ACD6B9Y3 (Hadesarchaea archaeon YNP_N21) Explore A0ACD6B9Y3 Go to UniProtKB: A0ACD6B9Y3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0ACD6B9Y3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM Query on HEM Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.261 (Depositor), 0.266 (DCC)
R-Value Work: 0.221 (Depositor), 0.229 (DCC)
R-Value Observed: 0.223 (Depositor)

Space Group: P 6₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.17	α = 90
b = 72.17	β = 90
c = 22.81	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing
PHENIX	refinement

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-03-06

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2019-03-06
Type: Initial release
Version 1.1: 2023-10-11
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.2: 2024-10-30
Changes: Structure summary
