6NY5 | pdb_00006ny5

Crystal structure of the PUM-HD domain of S. pombe Puf1 in complex with RNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.263 (Depositor), 0.265 (DCC)
  • R-Value Work:
    0.211 (Depositor), 0.215 (DCC)
  • R-Value Observed:
    0.215 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6NY5

This is version 1.2 of the entry. See complete history

Literature

Distinct RNA-binding modules in a single PUF protein cooperate to determine RNA specificity.

Qiu, C.Dutcher, R.C.Porter, D.F.Arava, Y.Wickens, M.Hall, T.M.T.

(2019) Nucleic Acids Res 47: 8770-8784

  • DOI: https://doi.org/10.1093/nar/gkz583
  • Primary Citation Related Structures:
    6NWW, 6NX5, 6NY5

  • PubMed Abstract:

    PUF proteins, named for Drosophila Pumilio (PUM) and Caenorhabditis elegans fem-3-binding factor (FBF), recognize specific sequences in the mRNAs they bind and control. RNA binding by classical PUF proteins is mediated by a characteristic PUM homology domain (PUM-HD). The Puf1 and Puf2 proteins possess a distinct architecture and comprise a highly conserved subfamily among fungal species. Puf1/Puf2 proteins contain two types of RNA-binding domain: a divergent PUM-HD and an RNA recognition motif (RRM). They recognize RNAs containing UAAU motifs, often in clusters. Here, we report a crystal structure of the PUM-HD of a fungal Puf1 in complex with a dual UAAU motif RNA. Each of the two UAAU tetranucleotides are bound by a Puf1 PUM-HD forming a 2:1 protein-to-RNA complex. We also determined crystal structures of the Puf1 RRM domain that identified a dimerization interface. The PUM-HD and RRM domains act in concert to determine RNA-binding specificity: the PUM-HD dictates binding to UAAU, and dimerization of the RRM domain favors binding to dual UAAU motifs rather than a single UAAU. Cooperative action of the RRM and PUM-HD identifies a new mechanism by which multiple RNA-binding modules in a single protein collaborate to create a unique RNA-binding specificity.


  • Organizational Affiliation
    • Epigenetics and Stem Cell Biology Laboratory, National Institute of Environmental Health Sciences, National Institutes of Health, Research Triangle Park, NC 27709, USA.

Macromolecule Content

  • Total Structure Weight: 93.85 kDa
  • Atom Count: 6,422
  • Modeled Residue Count: 769
  • Deposited Residue Count: 791
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Pumilio domain-containing protein C56F2.08c
A, B
389Schizosaccharomyces pombeMutation(s): 0
Gene Names: SPBC56F2.08c
UniProt
Find proteins for O60059 (Schizosaccharomyces pombe (strain 972 / ATCC 24843))
Explore O60059
Go to UniProtKB:  O60059
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO60059
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
RNA (5'-R(P*UP*UP*AP*AP*UP*AP*AP*CP*UP*UP*AP*AP*U)-3')13Schizosaccharomyces pombe
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.263 (Depositor), 0.265 (DCC)
  • R-Value Work:  0.211 (Depositor), 0.215 (DCC)
  • R-Value Observed: 0.215 (Depositor)
Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 159.677α = 90
b = 159.677β = 90
c = 215.53γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
AutoSolphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-03
    Type: Initial release
  • Version 1.1: 2020-01-15
    Changes: Database references
  • Version 1.2: 2024-10-30
    Changes: Data collection, Database references, Structure summary
