6N1R | pdb_00006n1r

Tetrahedral oligomeric complex of GyrA N-terminal fragment, solved by cryoEM in tetrahedral symmetry


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6N1R

This is version 1.2 of the entry. See complete history

Literature

CryoEM structures of open dimers of Gyrase A in complex with DNA illuminate mechanism of strand passage.

Soczek, K.M.Grant, T.Rosenthal, P.B.Mondragon, A.

(2018) Elife 7

  • DOI: https://doi.org/10.7554/eLife.41215
  • Primary Citation Related Structures:
    6N1P, 6N1Q, 6N1R

  • PubMed Abstract:

    Gyrase is a unique type IIA topoisomerase that uses ATP hydrolysis to maintain the negatively supercoiled state of bacterial DNA. In order to perform its function, gyrase undergoes a sequence of conformational changes that consist of concerted gate openings, DNA cleavage, and DNA strand passage events. Structures where the transported DNA molecule (T-segment) is trapped by the A subunit have not been observed. Here we present the cryoEM structures of two oligomeric complexes of open gyrase A dimers and DNA. The protein subunits in these complexes were solved to 4 Å and 5.2 Å resolution. One of the complexes traps a linear DNA molecule, a putative T-segment, which interacts with the open gyrase A dimers in two states, representing steps either prior to or after passage through the DNA-gate. The structures locate the T-segment in important intermediate conformations of the catalytic cycle and provide insights into gyrase-DNA interactions and mechanism.


  • Organizational Affiliation
    • Department of Molecular Biosciences, Northwestern University, Evanston, United States.

Macromolecule Content

  • Total Structure Weight: 695.73 kDa
  • Atom Count: 46,044
  • Modeled Residue Count: 5,796
  • Deposited Residue Count: 6,132
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA gyrase subunit A
A, B, C, D, E
A, B, C, D, E, F, G, H, I, J, K, L
511Streptococcus pneumoniae G54Mutation(s): 0
Gene Names: gyrA_1gyrAERS409327_01712
EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for Q8DPM2 (Streptococcus pneumoniae (strain ATCC BAA-255 / R6))
Explore Q8DPM2
Go to UniProtKB:  Q8DPM2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8DPM2
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION2.1
MODEL REFINEMENTREFMAC5
MODEL REFINEMENTPHENIX1.12-2829

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01-GM051350
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35-GM118108
Medical Research Council (MRC, United Kingdom)United KingdomFC001143
Cancer Research UKUnited KingdomFC001143
Wellcome TrustUnited KingdomFC001143

Revision History  (Full details and data files)

  • Version 1.0: 2018-12-05
    Type: Initial release
  • Version 1.1: 2020-01-08
    Changes: Author supporting evidence
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references, Refinement description
