6MGJ

Crystal structure of the catalytic domain from GH74 enzyme PoGH74 from Paenibacillus odorifer, apoenzyme


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.176
  • R-Value Work: 0.149
  • R-Value Observed: 0.149

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structural enzymology reveals the molecular basis of substrate regiospecificity and processivity of an exemplar bacterial glycoside hydrolase family 74endo-xyloglucanase.

Arnal, G.Stogios, P.J.Asohan, J.Skarina, T.Savchenko, A.Brumer, H.

(2018) Biochem J 475: 3963-3978

  • DOI: https://doi.org/10.1042/BCJ20180763
  • Primary Citation of Related Structures:
    6MGJ, 6MGK, 6MGL

  • PubMed Abstract:

    Paenibacillus odorifer produces a single multimodular enzyme containing a glycoside hydrolase (GH) family 74 module (AIQ73809). Recombinant production and characterization of the GH74 module ( Po GH74 cat ) revealed a highly specific, processive endo -xyloglucanase that can hydrolyze the polysaccharide backbone at both branched and unbranched positions. X-ray crystal structures obtained for the free enzyme and oligosaccharide complexes evidenced an extensive hydrophobic binding platform - the first in GH74 extending from subsites -4 to +6 - and unique mobile active-site loops. Site-directed mutagenesis revealed that glycine-476 was uniquely responsible for the promiscuous backbone-cleaving activity of Po GH74 cat ; replacement with tyrosine, which is conserved in many GH74 members, resulted in exclusive hydrolysis at unbranched glucose units. Likewise, systematic replacement of the hydrophobic platform residues constituting the positive subsites indicated their relative contributions to the processive mode of action. Specifically, W347 (+3 subsite) and W348 (+5 subsite) are essential for processivity, while W406 (+2 subsite) and Y372 (+6 subsite) are not strictly essential, but aid processivity.


  • Organizational Affiliation

    Michael Smith Laboratories, University of British Columbia, 2185 East Mall, Vancouver, BC V6T 1Z4, Canada.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Xyloglucanase
A, B, C, D, E
A, B, C, D, E, F, G, H
747Paenibacillus odoriferMutation(s): 0
Gene Names: BSK60_29080
UniProt
Find proteins for A0A1R0YRH0 (Paenibacillus odorifer)
Explore A0A1R0YRH0
Go to UniProtKB:  A0A1R0YRH0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1R0YRH0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PE3
Query on PE3

Download Ideal Coordinates CCD File
AA [auth C]
BB [auth G]
CB [auth G]
DA [auth D]
IB [auth H]
AA [auth C],
BB [auth G],
CB [auth G],
DA [auth D],
IB [auth H],
J [auth A],
K [auth A],
KA [auth E],
VA [auth F],
W [auth B],
WA [auth F],
XA [auth F]
3,6,9,12,15,18,21,24,27,30,33,36,39-TRIDECAOXAHENTETRACONTANE-1,41-DIOL
C28 H58 O15
ILLKMACMBHTSHP-UHFFFAOYSA-N
PO4
Query on PO4

Download Ideal Coordinates CCD File
EA [auth D]PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
GOL
Query on GOL

Download Ideal Coordinates CCD File
BA [auth C]
DB [auth G]
EB [auth G]
FA [auth D]
FB [auth G]
BA [auth C],
DB [auth G],
EB [auth G],
FA [auth D],
FB [auth G],
GA [auth D],
GB [auth G],
HA [auth D],
IA [auth D],
JB [auth H],
KB [auth H],
L [auth A],
LA [auth E],
LB [auth H],
M [auth A],
MA [auth E],
MB [auth H],
N [auth A],
NA [auth E],
NB [auth H],
O [auth A],
OA [auth E],
OB [auth H],
P [auth A],
PA [auth E],
Q [auth A],
QA [auth E],
R [auth A],
RA [auth E],
S [auth A],
SA [auth E],
T [auth A],
TA [auth E],
X [auth B],
Y [auth B],
ZA [auth F]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
YA [auth F]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG
Query on MG

Download Ideal Coordinates CCD File
AB [auth G]
CA [auth D]
HB [auth H]
I [auth A]
JA [auth E]
AB [auth G],
CA [auth D],
HB [auth H],
I [auth A],
JA [auth E],
U [auth B],
UA [auth F],
V [auth B],
Z [auth C]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D, E
A, B, C, D, E, F, G, H
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.176
  • R-Value Work: 0.149
  • R-Value Observed: 0.149
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 239.094α = 90
b = 226.674β = 114.07
c = 187.224γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHENIXphasing
PHENIXmodel building
Cootmodel building

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Natural Sciences and Engineering Research Council (NSERC, Canada)CanadaIndustrial Biocatalysis Network

Revision History  (Full details and data files)

  • Version 1.0: 2019-01-23
    Type: Initial release
  • Version 1.1: 2020-01-08
    Changes: Author supporting evidence
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.3: 2023-11-15
    Changes: Data collection
  • Version 1.4: 2024-11-20
    Changes: Structure summary
