6L76 | pdb_00006l76

Crystal structure of the Ni(II)(Chro)2-d(TTGGGCCGAA/TTCGGCCCAA) complex at 2.94 angstrom resolution


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:
    0.276 (Depositor), 0.284 (DCC)
  • R-Value Work:
    0.235 (Depositor), 0.261 (DCC)
  • R-Value Observed:
    0.239 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6L76

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Targeting the ALS/FTD-associated A-DNA kink with anthracene-based metal complex causes DNA backbone straightening and groove contraction.

Jhan, C.R.Satange, R.Wang, S.C.Zeng, J.Y.Horng, Y.C.Jin, P.Neidle, S.Hou, M.H.

(2021) Nucleic Acids Res 49: 9526-9538

  • DOI: https://doi.org/10.1093/nar/gkab227
  • Primary Citation Related Structures:
    6L75, 6L76, 7BPV

  • PubMed Abstract:

    The use of a small molecule compound to reduce toxic repeat RNA transcripts or their translated aberrant proteins to target repeat-expanded RNA/DNA with a G4C2 motif is a promising strategy to treat C9orf72-linked disorders. In this study, the crystal structures of DNA and RNA-DNA hybrid duplexes with the -GGGCCG- region as a G4C2 repeat motif were solved. Unusual groove widening and sharper bending of the G4C2 DNA duplex A-DNA conformation with B-form characteristics inside was observed. The G4C2 RNA-DNA hybrid duplex adopts a more typical rigid A form structure. Detailed structural analysis revealed that the G4C2 repeat motif of the DNA duplex exhibits a hydration shell and greater flexibility and serves as a 'hot-spot' for binding of the anthracene-based nickel complex, NiII(Chro)2 (Chro = Chromomycin A3). In addition to the original GGCC recognition site, NiII(Chro)2 has extended specificity and binds the flanked G:C base pairs of the GGCC core, resulting in minor groove contraction and straightening of the DNA backbone. We have also shown that Chro-metal complexes inhibit neuronal toxicity and suppresses locomotor deficits in a Drosophila model of C9orf72-associated ALS. The approach represents a new direction for drug discovery against ALS and FTD diseases by targeting G4C2 repeat motif DNA.


  • Organizational Affiliation
    • Department of Life Sciences, National Chung-Hsing University, Taichung 402, Taiwan.

Macromolecule Content

  • Total Structure Weight: 17.28 kDa
  • Atom Count: 1,168
  • Modeled Residue Count: 39
  • Deposited Residue Count: 40
  • Unique nucleic acid chains: 2

Macromolecules

Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*TP*TP*GP*GP*GP*CP*CP*GP*AP*A)-3')
A, D
10synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*TP*TP*CP*GP*GP*CP*CP*CP*AP*A)-3')
B, C
10synthetic construct
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 3
MoleculeChains Length2D Diagram GlycosylationD Interactions
2,6-dideoxy-4-O-methyl-alpha-D-galactopyranose-(1-3)-(2R,3R,6R)-6-hydroxy-2-methyltetrahydro-2H-pyran-3-yl acetate
E, H, I, K
2N/A
Glycosylation Resources
GlyTouCan: G66610ZG
GlyCosmos: G66610ZG
Entity ID: 4
MoleculeChains Length2D Diagram GlycosylationD Interactions
3-C-methyl-4-O-acetyl-alpha-L-Olivopyranose-(1-3)-(2R,5S,6R)-6-methyltetrahydro-2H-pyran-2,5-diol-(1-3)-(2R,5S,6R)-6-methyltetrahydro-2H-pyran-2,5-diol
F, G, J, L
3N/A
Glycosylation Resources
GlyTouCan: G76712GN
GlyCosmos: G76712GN

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CPH

Query on CPH



Download:Ideal Coordinates CCD File
M [auth A],
P [auth B],
R [auth C],
T [auth D]
(1S)-5-deoxy-1-O-methyl-1-C-[(2R,3S)-3,5,7,10-tetrahydroxy-6-methyl-4-oxo-1,2,3,4-tetrahydroanthracen-2-yl]-D-xylulose
C21 H24 O9
AOCJXLJIUYHXRS-PKRZCTMMSA-N
NI

Query on NI



Download:Ideal Coordinates CCD File
N [auth A]
O [auth A]
Q [auth B]
S [auth C]
U [auth D]
N [auth A],
O [auth A],
Q [auth B],
S [auth C],
U [auth D],
V [auth D],
W [auth D]
NICKEL (II) ION
Ni
VEQPNABPJHWNSG-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:  0.276 (Depositor), 0.284 (DCC)
  • R-Value Work:  0.235 (Depositor), 0.261 (DCC)
  • R-Value Observed: 0.239 (Depositor)
Space Group: P 65 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.718α = 90
b = 64.718β = 90
c = 246.578γ = 120
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXrefinement
MOLREPphasing
HKL-2000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-01-13
    Type: Initial release
  • Version 1.1: 2021-05-26
    Changes: Database references
  • Version 1.2: 2021-10-06
    Changes: Database references
  • Version 1.3: 2023-11-22
    Changes: Data collection, Refinement description
