6KUZ | pdb_00006kuz

E.coli beta-galactosidase (E537Q) in complex with fluorescent probe KSL01


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.83 Å
  • R-Value Free:
    0.224 (Depositor), 0.224 (DCC)
  • R-Value Work:
    0.182 (Depositor), 0.185 (DCC)
  • R-Value Observed:
    0.184 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6KUZ

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

First-generation species-selective chemical probes for fluorescence imaging of human senescence-associated beta-galactosidase.

Li, X.Qiu, W.Li, J.Chen, X.Hu, Y.Gao, Y.Shi, D.Li, X.Lin, H.Hu, Z.Dong, G.Sheng, C.Jiang, B.Xia, C.Kim, C.Y.Guo, Y.Li, J.

(2020) Chem Sci 11: 7292-7301

  • DOI: https://doi.org/10.1039/d0sc01234c
  • Primary Citation Related Structures:
    6KUZ

  • PubMed Abstract:

    Human senescence-associated β-galactosidase (SA-β-gal), the most widely used biomarker of aging, is a valuable tool for assessing the extent of cell 'healthy aging' and potentially predicting the health life span of an individual. Human SA-β-gal is an endogenous lysosomal enzyme expressed from GLB1 , the catalytic domain of which is very different from that of E. coli β-gal, a bacterial enzyme encoded by lacZ . However, existing chemical probes for this marker still lack the ability to distinguish human SA-β-gal from β-gal of other species, such as bacterial β-gal, which can yield false positive signals. Here, we show a molecular design strategy to construct fluorescent probes with the above ability with the aid of structure-based steric hindrance adjustment catering to different enzyme pockets. The resulting probes normally work as traditional SA-β-gal probes, but they are unique in their powerful ability to distinguish human SA-β-gal from E. coli β-gal, thus achieving species-selective visualization of human SA-β-gal for the first time. NIR-emitting fluorescent probe KSL11 as their representative further displays excellent species-selective recognition performance in biological systems, which has been herein verified by testing in senescent cells, in lacZ -transfected cells and in E. coli -β-gal-contaminated tissue sections of mice. Because of our probes, it was also discovered that SA-β-gal content in mice increased gradually with age and SA-β-gal accumulated most in the kidneys among the main organs of naturally aging mice, suggesting that the kidneys are the organs with the most severe aging during natural aging.


  • Organizational Affiliation
    • State Key Laboratory of Bioreactor Engineering, Shanghai Key Laboratory of New Drug Design, School of Pharmacy, East China University of Science and Technology Shanghai 200237 China jianli@ecust.edu.cn.

Macromolecule Content

  • Total Structure Weight: 471.85 kDa
  • Atom Count: 33,232
  • Modeled Residue Count: 4,083
  • Deposited Residue Count: 4,096
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-galactosidase
A, B, C, D
1,024Escherichia coli K-12Mutation(s): 1
Gene Names: lacZb0344JW0335
EC: 3.2.1.23
UniProt
Find proteins for P00722 (Escherichia coli (strain K12))
Explore P00722
Go to UniProtKB:  P00722
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00722
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
DVL
(Subject of Investigation/LOI)

Query on DVL



Download:Ideal Coordinates CCD File
E [auth A],
LA [auth C],
WA [auth D],
X [auth B]
3-(1,3-benzothiazol-2-yl)-2-[[4-[(2~{S},3~{R},4~{S},5~{R},6~{R})-6-(hydroxymethyl)-3,4,5-tris(oxidanyl)oxan-2-yl]oxyphenyl]methoxy]-5-methyl-benzaldehyde
C28 H27 N O8 S
OIAKZSZIDGSPEQ-WRPMCVFTSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
JB [auth D]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
DMS

Query on DMS



Download:Ideal Coordinates CCD File
AB [auth D]
BA [auth B]
BB [auth D]
CA [auth B]
CB [auth D]
AB [auth D],
BA [auth B],
BB [auth D],
CA [auth B],
CB [auth D],
DA [auth B],
DB [auth D],
EA [auth B],
EB [auth D],
FA [auth B],
FB [auth D],
GA [auth B],
GB [auth D],
HA [auth B],
HB [auth D],
I [auth A],
IA [auth B],
IB [auth D],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
PA [auth C],
Q [auth A],
QA [auth C],
R [auth A],
RA [auth C],
S [auth A],
SA [auth C],
T [auth A],
TA [auth C],
U [auth A]
DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
JA [auth B]
KA [auth B]
KB [auth D]
LB [auth D]
UA [auth C]
JA [auth B],
KA [auth B],
KB [auth D],
LB [auth D],
UA [auth C],
V [auth A],
VA [auth C],
W [auth A]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
AA [auth B]
F [auth A]
G [auth A]
H [auth A]
MA [auth C]
AA [auth B],
F [auth A],
G [auth A],
H [auth A],
MA [auth C],
NA [auth C],
OA [auth C],
XA [auth D],
Y [auth B],
YA [auth D],
Z [auth B],
ZA [auth D]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.83 Å
  • R-Value Free:  0.224 (Depositor), 0.224 (DCC)
  • R-Value Work:  0.182 (Depositor), 0.185 (DCC)
  • R-Value Observed: 0.184 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 248.174α = 90
b = 85.506β = 94.09
c = 243.052γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-08
    Type: Initial release
  • Version 1.1: 2021-06-30
    Changes: Database references, Derived calculations
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
