6KOK | pdb_00006kok

Crystal Structure of SNX11/SNX10-PXe Chimera


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.250 (Depositor), 0.254 (DCC)
  • R-Value Work:
    0.204 (Depositor), 0.206 (DCC)
  • R-Value Observed:
    0.206 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6KOK

This is version 1.2 of the entry. See complete history

Literature

Molecular Basis for PI(3,5)P2Recognition by SNX11, a Protein Involved in Lysosomal Degradation and Endosome Homeostasis Regulation.

Xu, T.Gan, Q.Wu, B.Yin, M.Xu, J.Shu, X.Liu, J.

(2020) J Mol Biology 432: 4750-4761

  • DOI: https://doi.org/10.1016/j.jmb.2020.06.010
  • Primary Citation Related Structures:
    6KOI, 6KOJ, 6KOK

  • PubMed Abstract:

    Phosphatidylinositol 3,5-bisphosphate (PI(3,5)P 2 ) is an essential phosphoinositide required for endosome homeostasis and sorting for lysosomal degradation; however, the underlying mechanisms, especially in mammals, remain elusive or unexplored. Here we determined a structure of PI(3,5)P 2 bound to Sorting Nexin 11 (SNX11) with an opened PPII-C loop. We also obtained an SNX11 structure with its PPII-C in "closed" form that serves as a potential PI3P-binding model. In addition, our results reveal that SNX11 can interact with the V1D subunit of vacuolar H + -ATPase (V-ATPase), which provides a link between PI(3,5)P 2 and human V-ATPase and further evidence for their roles in the endosome homeostasis regulation. Lastly, a new apo-form structure of SNX11, combined with molecular dynamics (MD) studies, indicates that the α5 helix can unfold from the PX domain of SNX11 when targeting the membrane or interacting with its partner. Taken together, these findings identify a novel PI(3,5)P 2 effector, which will shed light on the PIs recognizing mechanism and the understanding of the downstream sorting events triggered by different PI binding.


  • Organizational Affiliation
    • State Key Laboratory of Respiratory Disease, Guangzhou Institutes of Biomedicine and Health, Chinese Academy of Sciences, Guangzhou 510530, China; Guangdong Provincial Key Laboratory of Biocomputing, Guangzhou Institutes of Biomedicine and Health, Chinese Academy of Sciences, Guangzhou 510530, China. Electronic address: xu_tingting@gibh.ac.cn.

Macromolecule Content

  • Total Structure Weight: 37.97 kDa
  • Atom Count: 2,699
  • Modeled Residue Count: 295
  • Deposited Residue Count: 320
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Sorting nexin-11,Uncharacterized protein SNX10
A, B
160Homo sapiensMutation(s): 0
Gene Names: SNX11SNX10
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y5W9 (Homo sapiens)
Explore Q9Y5W9
Go to UniProtKB:  Q9Y5W9
PHAROS:  Q9Y5W9
GTEx:  ENSG00000002919
Find proteins for Q9Y5X0 (Homo sapiens)
Explore Q9Y5X0
Go to UniProtKB:  Q9Y5X0
PHAROS:  Q9Y5X0
GTEx:  ENSG00000086300
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsQ9Y5X0Q9Y5W9
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CL

Query on CL



Download:Ideal Coordinates CCD File
C [auth A]
D [auth A]
E [auth A]
F [auth A]
G [auth A]
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth B],
L [auth B],
M [auth B],
N [auth B],
O [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA

Query on NA



Download:Ideal Coordinates CCD File
P [auth B]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.250 (Depositor), 0.254 (DCC)
  • R-Value Work:  0.204 (Depositor), 0.206 (DCC)
  • R-Value Observed: 0.206 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.103α = 90
b = 47.91β = 94.39
c = 87.309γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
PDB_EXTRACTdata extraction
MOSFLMdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data

  • Released Date: 2020-07-08
  • Deposition Author(s): Xu, T., Liu, J.

Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)China31570759

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-08
    Type: Initial release
  • Version 1.1: 2020-08-12
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
