6K76 | pdb_00006k76

Glycerol kinase form Thermococcus kodakarensis, complex structure with substrate.

PDB DOI: https://doi.org/10.2210/pdb6K76/pdb

Classification: TRANSFERASE
Organism(s): Thermococcus kodakarensis KOD1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-06-06 Released: 2020-06-10
Deposition Author(s): Koga, Y., Angkawidjaja, C., Matsumura, H., Hokao, R.
Funding Organization(s): Ministry of Education, Culture, Sports, Science and Technology (Japan)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.05 Å
R-Value Free:
0.261 (Depositor), 0.266 (DCC)
R-Value Work:
0.185 (Depositor), 0.187 (DCC)
R-Value Observed:
0.189 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6K76

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structural analysis of hexameric structure of glycerol kinase from Thermococcus kodakaraeinsis KOD1

Hokao, R., Matsumura, H., Katsumi, R., Angkawidjaja, C., Takano, K., Kanaya, S., Koga, Y.

To be published.

Macromolecule Content

Total Structure Weight: 112.95 kDa
Atom Count: 7,736
Modeled Residue Count: 967
Deposited Residue Count: 994
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycerol kinase	A, B	497	Thermococcus kodakarensis KOD1	Mutation(s): 0 Gene Names: glpK, TK1396 EC: 2.7.1.30
UniProt
Find proteins for O93623 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1)) Explore O93623 Go to UniProtKB: O93623
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O93623
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ANP Query on ANP Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C₁₀ H₁₇ N₆ O₁₂ P₃ PVKSNHVPLWYQGJ-KQYNXXCUSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.05 Å
R-Value Free: 0.261 (Depositor), 0.266 (DCC)
R-Value Work: 0.185 (Depositor), 0.187 (DCC)
R-Value Observed: 0.189 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 218.862	α = 90
b = 218.862	β = 90
c = 66.244	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-06-10

Deposition Author(s):

Angkawidjaja, C.

Funding Organization	Location	Grant Number
Ministry of Education, Culture, Sports, Science and Technology (Japan)	Japan	JP22780091

Revision History (Full details and data files)

Version 1.0: 2020-06-10
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references
