6IC5 | pdb_00006ic5

Human cathepsin-C in complex with dipeptidyl cyclopropyl nitrile inhibitor 2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.198 (Depositor), 0.205 (DCC)
  • R-Value Work:
    0.152 (Depositor), 0.164 (DCC)

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted HB5Click on this verticalbar to view details

This is version 2.1 of the entry. See complete history


Literature

Structure-based design and in vivo anti-arthritic activity evaluation of a potent dipeptidyl cyclopropyl nitrile inhibitor of cathepsin C.

Korkmaz, B.Lesner, A.Wysocka, M.Gieldon, A.Hakansson, M.Gauthier, F.Logan, D.T.Jenne, D.E.Lauritzen, C.Pedersen, J.

(2019) Biochem Pharmacol 164: 349-367

  • DOI: https://doi.org/10.1016/j.bcp.2019.04.006
  • Primary Citation of Related Structures:
    6IC5, 6IC6, 6IC7

  • PubMed Abstract:

    Cathepsin C (CatC) is a dipeptidyl-exopeptidase which activates neutrophil serine protease precursors (elastase, proteinase 3, cathepsin G and NSP4) by removing their N-terminal propeptide in bone marrow cells at the promyelocytic stage of neutrophil differentiation. The resulting active proteases are implicated in chronic inflammatory and autoimmune diseases. Hence, inhibition of CatC represents a therapeutic strategy to suppress excessive protease activities in various neutrophil mediated diseases. We designed and synthesized a series of dipeptidyl cyclopropyl nitrile compounds as putative CatC inhibitors. One compound, IcatC XPZ-01 ((S)-2-amino-N-((1R,2R)-1-cyano-2-(4'-(4-methylpiperazin-1-ylsulfonyl)biphenyl-4-yl)cyclopropyl)butanamide)) was identified as a potent inhibitor of both human and rodent CatC. In mice, pharmacokinetic studies revealed that IcatC XPZ-01 accumulated in the bone marrow reaching levels suitable for CatC inhibition. Subcutaneous administration of IcatC XPZ-01 in a monoclonal anti-collagen antibody induced mouse model of rheumatoid arthritis resulted in statistically significant anti-arthritic activity with persistent decrease in arthritis scores and paw thickness.


  • Organizational Affiliation

    INSERM, UMR 1100, "Centre d'Etude des Pathologies Respiratoires", 37032 Tours, France; Université de Tours, 37032 Tours, France. Electronic address: brice.korkmaz@inserm.fr.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Dipeptidyl peptidase 1119Homo sapiensMutation(s): 0
Gene Names: CTSCCPPI
EC: 3.4.14.1
UniProt & NIH Common Fund Data Resources
Find proteins for P53634 (Homo sapiens)
Explore P53634
Go to UniProtKB:  P53634
PHAROS:  P53634
GTEx:  ENSG00000109861
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53634
Glycosylation
Glycosylation Sites: 2Go to GlyGen: P53634-1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Dipeptidyl peptidase 1162Homo sapiensMutation(s): 0
Gene Names: CTSCCPPI
EC: 3.4.14.1
UniProt & NIH Common Fund Data Resources
Find proteins for P53634 (Homo sapiens)
Explore P53634
Go to UniProtKB:  P53634
PHAROS:  P53634
GTEx:  ENSG00000109861
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53634
Glycosylation
Glycosylation Sites: 1Go to GlyGen: P53634-1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Dipeptidyl peptidase 169Homo sapiensMutation(s): 0
Gene Names: CTSCCPPI
EC: 3.4.14.1
UniProt & NIH Common Fund Data Resources
Find proteins for P53634 (Homo sapiens)
Explore P53634
Go to UniProtKB:  P53634
PHAROS:  P53634
GTEx:  ENSG00000109861
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53634
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-3)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
D
5N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42227JK
GlyCosmos:  G42227JK
GlyGen:  G42227JK
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.198 (Depositor), 0.205 (DCC)
  • R-Value Work:  0.152 (Depositor), 0.164 (DCC)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.975α = 90
b = 88.329β = 90
c = 115.183γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PROTEUM2data reduction
SCALAdata scaling
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted HB5Click on this verticalbar to view details

Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Polish National Science CentrePoland2014/15/B/ST5/05311

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-24
    Type: Initial release
  • Version 1.1: 2019-05-22
    Changes: Data collection, Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2024-11-06
    Changes: Data collection, Database references, Derived calculations, Structure summary
