6HXY | pdb_00006hxy

Crystal structure of the head and coiled-coil domains of zebrafish CCDC61


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.258 (Depositor), 0.246 (DCC)
  • R-Value Work:
    0.200 (Depositor)
  • R-Value Observed:
    0.206 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6HXY

This is version 1.4 of the entry. See complete history

Literature

CCDC61/VFL3 Is a Paralog of SAS6 and Promotes Ciliary Functions.

Ochi, T.Quarantotti, V.Lin, H.Jullien, J.Rosa E Silva, I.Boselli, F.Barnabas, D.D.Johnson, C.M.McLaughlin, S.H.Freund, S.M.V.Blackford, A.N.Kimata, Y.Goldstein, R.E.Jackson, S.P.Blundell, T.L.Dutcher, S.K.Gergely, F.van Breugel, M.

(2020) Structure 28: 674

  • DOI: https://doi.org/10.1016/j.str.2020.04.010
  • Primary Citation Related Structures:
    6HXT, 6HXV, 6HXY

  • PubMed Abstract:

    Centrioles are cylindrical assemblies whose peripheral microtubule array displays a 9-fold rotational symmetry that is established by the scaffolding protein SAS6. Centriole symmetry can be broken by centriole-associated structures, such as the striated fibers in Chlamydomonas that are important for ciliary function. The conserved protein CCDC61/VFL3 is involved in this process, but its exact role is unclear. Here, we show that CCDC61 is a paralog of SAS6. Crystal structures of CCDC61 demonstrate that it contains two homodimerization interfaces that are similar to those found in SAS6, but result in the formation of linear filaments rather than rings. Furthermore, we show that CCDC61 binds microtubules and that residues involved in CCDC61 microtubule binding are important for ciliary function in Chlamydomonas. Together, our findings suggest that CCDC61 and SAS6 functionally diverged from a common ancestor while retaining the ability to scaffold the assembly of basal body-associated structures or centrioles, respectively.


  • Organizational Affiliation
    • MRC Laboratory of Molecular Biology, Cambridge Biomedical Campus, Francis Crick Avenue, Cambridge CB2 0QH, UK. Electronic address: T.Ochi@leeds.ac.uk.

Macromolecule Content

  • Total Structure Weight: 39.07 kDa
  • Atom Count: 2,362
  • Modeled Residue Count: 300
  • Deposited Residue Count: 346
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Coiled-coil domain-containing protein 61
A, B
173Danio rerioMutation(s): 0
Gene Names: ccdc61zgc:153153
UniProt
Find proteins for Q08CF3 (Danio rerio)
Explore Q08CF3
Go to UniProtKB:  Q08CF3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08CF3
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.258 (Depositor), 0.246 (DCC)
  • R-Value Work:  0.200 (Depositor)
  • R-Value Observed: 0.206 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.088α = 90
b = 100.56β = 90
c = 135.759γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
MOSFLMdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Medical Research Council (United Kingdom)United Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-29
    Type: Initial release
  • Version 1.1: 2020-05-06
    Changes: Database references
  • Version 1.2: 2020-05-20
    Changes: Database references
  • Version 1.3: 2020-06-10
    Changes: Database references
  • Version 1.4: 2024-01-24
    Changes: Data collection, Database references, Refinement description
