6HBE

Cu-containing nitrite reductase (NirK) from Thermus scotoductus SA-01


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.63 Å
  • R-Value Free: 0.190
  • R-Value Work: 0.161
  • R-Value Observed: 0.163

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A three-domain copper-nitrite reductase with a unique sensing loop.

Opperman, D.J.Murgida, D.H.Dalosto, S.D.Brondino, C.D.Ferroni, F.M.

(2019) IUCrJ 6: 248-258

  • DOI: https://doi.org/10.1107/S2052252519000241
  • Primary Citation of Related Structures:
    6HBE

  • PubMed Abstract:

    Dissimilatory nitrite reductases are key enzymes in the denitrification pathway, reducing nitrite and leading to the production of gaseous products (NO, N 2 O and N 2 ). The reaction is catalysed either by a Cu-containing nitrite reductase (NirK) or by a cytochrome cd 1 nitrite reductase (NirS), as the simultaneous presence of the two enzymes has never been detected in the same microorganism. The thermophilic bacterium Thermus scotoductus SA-01 is an exception to this rule, harbouring both genes within a denitrification cluster, which encodes for an atypical NirK. The crystal structure of Ts NirK has been determined at 1.63 Å resolution. Ts NirK is a homotrimer with subunits of 451 residues that contain three copper atoms each. The N-terminal region possesses a type 2 Cu (T2Cu) and a type 1 Cu (T1Cu N ) while the C-terminus contains an extra type 1 Cu (T1Cu C ) bound within a cupredoxin motif. T1Cu N shows an unusual Cu atom coordination (His 2 -Cys-Gln) compared with T1Cu observed in NirKs reported so far (His 2 -Cys-Met). T1Cu C is buried at ∼5 Å from the molecular surface and located ∼14.1 Å away from T1Cu N ; T1Cu N and T2Cu are ∼12.6 Å apart. All these distances are compatible with an electron-transfer process T1Cu C → T1Cu N → T2Cu. T1Cu N and T2Cu are connected by a typical Cys-His bridge and an unexpected sensing loop which harbours a Ser CAT residue close to T2Cu, suggesting an alternative nitrite-reduction mechanism in these enzymes. Biophysicochemical and functional features of Ts NirK are discussed on the basis of X-ray crystallography, electron paramagnetic resonance, resonance Raman and kinetic experiments.


  • Organizational Affiliation

    Department of Biotechnology, University of the Free State, 205 Nelson Mandela Drive, Bloemfontein, Free State 9300, South Africa.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Copper-containing nitrite reductase
A, B, C
451Thermus scotoductus SA-01Mutation(s): 0
Gene Names: TSC_c17620
EC: 1.7.2.1
UniProt
Find proteins for E8PLV7 (Thermus scotoductus (strain ATCC 700910 / SA-01))
Explore E8PLV7
Go to UniProtKB:  E8PLV7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupE8PLV7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CU
Query on CU

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
H [auth B]
I [auth B]
D [auth A],
E [auth A],
F [auth A],
H [auth B],
I [auth B],
J [auth B],
L [auth C],
M [auth C],
N [auth C]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
G [auth A],
K [auth B],
O [auth C]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.63 Å
  • R-Value Free: 0.190
  • R-Value Work: 0.161
  • R-Value Observed: 0.163
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 145.692α = 90
b = 110.553β = 107.51
c = 88.81γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
autoPROCdata scaling
Aimlessdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-01-23
    Type: Initial release
  • Version 1.1: 2019-03-27
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-17
    Changes: Data collection, Database references, Derived calculations, Refinement description
