6H78 | pdb_00006h78

E1 enzyme for ubiquitin like protein activation.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.242 (Depositor), 0.241 (DCC)
  • R-Value Work:
    0.190 (Depositor), 0.189 (DCC)
  • R-Value Observed:
    0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6H78

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

An N-Terminal Extension to UBA5 Adenylation Domain Boosts UFM1 Activation: Isoform-Specific Differences in Ubiquitin-like Protein Activation.

Soudah, N.Padala, P.Hassouna, F.Kumar, M.Mashahreh, B.Lebedev, A.A.Isupov, M.N.Cohen-Kfir, E.Wiener, R.

(2019) J Mol Biology 431: 463-478

  • DOI: https://doi.org/10.1016/j.jmb.2018.10.007
  • Primary Citation Related Structures:
    6H77, 6H78

  • PubMed Abstract:

    Modification of proteins by the ubiquitin-like protein, UFM1, requires activation of UFM1 by the E1-activating enzyme, UBA5. In humans, UBA5 possesses two isoforms, each comprising an adenylation domain, but only one containing an N-terminal extension. Currently, the role of the N-terminal extension in UFM1 activation is not clear. Here we provide structural and biochemical data on UBA5 N-terminal extension to understand its contribution to UFM1 activation. The crystal structures of the UBA5 long isoform bound to ATP with and without UFM1 show that the N-terminus not only is directly involved in ATP binding but also affects how the adenylation domain interacts with ATP. Surprisingly, in the presence of the N-terminus, UBA5 no longer retains the 1:2 ratio of ATP to UBA5, but rather this becomes a 1:1 ratio. Accordingly, the N-terminus significantly increases the affinity of ATP to UBA5. Finally, the N-terminus, although not directly involved in the E2 binding, stimulates transfer of UFM1 from UBA5 to the E2, UFC1.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biology, The Institute for Medical Research Israel-Canada, Hebrew University-Hadassah Medical School, Jerusalem 91120, Israel.

Macromolecule Content

  • Total Structure Weight: 545.13 kDa
  • Atom Count: 36,069
  • Modeled Residue Count: 4,460
  • Deposited Residue Count: 4,800
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ubiquitin-like modifier-activating enzyme 5
A, B, C, D, E
A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P
300Homo sapiensMutation(s): 0
Gene Names: UBA5UBE1DC1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9GZZ9 (Homo sapiens)
Explore Q9GZZ9
Go to UniProtKB:  Q9GZZ9
PHAROS:  Q9GZZ9
GTEx:  ENSG00000081307
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9GZZ9
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP

Query on ATP



Download:Ideal Coordinates CCD File
ED [auth O]
FB [auth G]
FC [auth K]
GA [auth C]
LA [auth D]
ED [auth O],
FB [auth G],
FC [auth K],
GA [auth C],
LA [auth D],
LD [auth P],
MB [auth H],
MC [auth L],
Q [auth A],
RB [auth I],
SA [auth E],
TC [auth M],
VB [auth J],
X [auth B],
YA [auth F],
ZC [auth N]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
AB [auth F]
BD [auth N]
GD [auth O]
HB [auth G]
HC [auth K]
AB [auth F],
BD [auth N],
GD [auth O],
HB [auth G],
HC [auth K],
IA [auth C],
NA [auth D],
ND [auth P],
OB [auth H],
OC [auth L],
S [auth A],
TB [auth I],
UA [auth E],
VC [auth M],
XB [auth J],
Z [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
AC [auth J]
BA [auth B]
BC [auth J]
CA [auth B]
CB [auth F]
AC [auth J],
BA [auth B],
BC [auth J],
CA [auth B],
CB [auth F],
CC [auth J],
DA [auth B],
DB [auth F],
DC [auth J],
DD [auth N],
EA [auth B],
EB [auth F],
EC [auth J],
FA [auth B],
ID [auth O],
JB [auth G],
JC [auth K],
JD [auth O],
KA [auth C],
KB [auth G],
KC [auth K],
KD [auth O],
LB [auth G],
PA [auth D],
PD [auth P],
QA [auth D],
QB [auth H],
QC [auth L],
QD [auth P],
RA [auth D],
RC [auth L],
RD [auth P],
SC [auth L],
SD [auth P],
U [auth A],
V [auth A],
W [auth A],
WA [auth E],
XA [auth E],
XC [auth M],
YC [auth M],
ZB [auth J]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
LC [auth K]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG

Query on MG



Download:Ideal Coordinates CCD File
AA [auth B]
AD [auth N]
BB [auth F]
CD [auth N]
FD [auth O]
AA [auth B],
AD [auth N],
BB [auth F],
CD [auth N],
FD [auth O],
GB [auth G],
GC [auth K],
HA [auth C],
HD [auth O],
IB [auth G],
IC [auth K],
JA [auth C],
MA [auth D],
MD [auth P],
NB [auth H],
NC [auth L],
OA [auth D],
OD [auth P],
PB [auth H],
PC [auth L],
R [auth A],
SB [auth I],
T [auth A],
TA [auth E],
UB [auth I],
UC [auth M],
VA [auth E],
WB [auth J],
WC [auth M],
Y [auth B],
YB [auth J],
ZA [auth F]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.242 (Depositor), 0.241 (DCC)
  • R-Value Work:  0.190 (Depositor), 0.189 (DCC)
  • R-Value Observed: 0.190 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 143.86α = 90
b = 151.933β = 93.07
c = 153.543γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Israel Science Foundation--

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-31
    Type: Initial release
  • Version 1.1: 2019-04-24
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-17
    Changes: Data collection, Database references, Derived calculations, Refinement description
