 6GZV | pdb_00006gzv

Identification of a druggable VP1-VP3 interprotomer pocket in the capsid of enteroviruses

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6GZV

This is version 1.3 of the entry. See complete history.

Literature

A novel druggable interprotomer pocket in the capsid of rhino- and enteroviruses.

Abdelnabi, R., Geraets, J.A., Ma, Y., Mirabelli, C., Flatt, J.W., Domanska, A., Delang, L., Jochmans, D., Kumar, T.A., Jayaprakash, V., Sinha, B.N., Leyssen, P., Butcher, S.J., Neyts, J.

(2019) PLoS Biol 17: e3000281-e3000281

  • DOI: https://doi.org/10.1371/journal.pbio.3000281
  • Primary Citation Related Structures:
    6GZV

  • PubMed Abstract:

    Rhino- and enteroviruses are important human pathogens, against which no antivirals are available. The best-studied inhibitors are "capsid binders" that fit in a hydrophobic pocket of the viral capsid. Employing a new class of entero-/rhinovirus inhibitors and by means of cryo-electron microscopy (EM), followed by resistance selection and reverse genetics, we discovered a hitherto unknown druggable pocket that is formed by viral proteins VP1 and VP3 and that is conserved across entero-/rhinovirus species. We propose that these inhibitors stabilize a key region of the virion, thereby preventing the conformational expansion needed for viral RNA release. A medicinal chemistry effort resulted in the identification of analogues targeting this pocket with broad-spectrum activity against Coxsackieviruses B (CVBs) and compounds with activity against enteroviruses (EV) of groups C and D, and even rhinoviruses (RV). Our findings provide novel insights in the biology of the entry of entero-/rhinoviruses and open new avenues for the design of broad-spectrum antivirals against these pathogens.

    • Organizational Affiliation:
    • Department of Microbiology and Immunology, Rega Institute for Medical Research, Laboratory of Virology and Chemotherapy, KU Leuven, Leuven, Belgium.

Macromolecule Content

  • Total Structure Weight: 94.67 kDa
  • Atom Count: 6,394
  • Modeled Residue Count: 818
  • Deposited Residue Count: 854
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Capsid protein VP1284Coxsackievirus B3 (strain Nancy)Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for P03313 (Coxsackievirus B3 (strain Nancy))
Explore P03313
Go to UniProtKB:  P03313
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03313
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Capsid protein VP2263Coxsackievirus B3 (strain Nancy)Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for P03313 (Coxsackievirus B3 (strain Nancy))
Explore P03313
Go to UniProtKB:  P03313
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03313
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Capsid protein VP3238Coxsackievirus B3 (strain Nancy)Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for P03313 (Coxsackievirus B3 (strain Nancy))
Explore P03313
Go to UniProtKB:  P03313
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03313
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Capsid protein VP469Coxsackievirus B3 (strain Nancy)Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for P03313 (Coxsackievirus B3 (strain Nancy))
Explore P03313
Go to UniProtKB:  P03313
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03313
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FHK

Query on FHK


Download:Ideal Coordinates CCD File
E [auth C]4-[[4-[1,3-bis(oxidanylidene)isoindol-2-yl]phenyl]sulfonylamino]benzoic acid
C21 H14 N2 O6 S
KCHARURJHJMOQX-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION2.1.beta
MODEL REFINEMENTMDFF0.5
MODEL REFINEMENTCoot0.8.8

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
European UnionFinland612308

Revision History  (Full details and data files)

  • Version 1.0: 2019-06-05
    Type: Initial release
  • Version 1.1: 2019-06-12
    Changes: Data collection
  • Version 1.2: 2019-06-19
    Changes: Data collection, Database references
  • Version 1.3: 2024-05-15
    Changes: Data collection, Database references, Derived calculations
