6GEN

Chromatin remodeller-nucleosome complex at 4.5 A resolution.


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.60 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structure and dynamics of the yeast SWR1-nucleosome complex.

Willhoft, O.Ghoneim, M.Lin, C.L.Chua, E.Y.D.Wilkinson, M.Chaban, Y.Ayala, R.McCormack, E.A.Ocloo, L.Rueda, D.S.Wigley, D.B.

(2018) Science 362

  • DOI: https://doi.org/10.1126/science.aat7716
  • Primary Citation of Related Structures:
    6GEJ, 6GEN

  • PubMed Abstract:

    The yeast SWR1 complex exchanges histone H2A in nucleosomes with Htz1 (H2A.Z in humans). The cryo-electron microscopy structure of the SWR1 complex bound to a nucleosome at 3.6-angstrom resolution reveals details of the intricate interactions between components of the SWR1 complex and its nucleosome substrate. Interactions between the Swr1 motor domains and the DNA wrap at superhelical location 2 distort the DNA, causing a bulge with concomitant translocation of the DNA by one base pair, coupled to conformational changes of the histone core. Furthermore, partial unwrapping of the DNA from the histone core takes place upon binding of nucleosomes to SWR1 complex. The unwrapping, as monitored by single-molecule data, is stabilized and has its dynamics altered by adenosine triphosphate binding but does not require hydrolysis.


  • Organizational Affiliation

    Section of Structural Biology, Department of Medicine, Imperial College London, London SW7 2AZ, UK.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar protein sorting-associated protein 72A [auth Z]131Saccharomyces cerevisiae S288CMutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3B [auth A],
C [auth B]
136Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: HHT1YBR010WYBR0201HHT2SIN2YNL031CN2749
UniProt
Find proteins for P61830 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P61830
Go to UniProtKB:  P61830
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61830
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4D [auth C],
E [auth D]
103Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: HHF1YBR009CYBR0122HHF2YNL030WN2752
UniProt
Find proteins for P02309 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P02309
Go to UniProtKB:  P02309
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02309
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2A.1F [auth E],
G [auth F]
132Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: HTA1H2A1SPT11YDR225WYD9934.10
UniProt
Find proteins for P04911 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P04911
Go to UniProtKB:  P04911
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04911
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2B.1H [auth G],
I [auth H]
131Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: HTB1H2B1SPT12YDR224CYD9934.09C
UniProt
Find proteins for P02293 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P02293
Go to UniProtKB:  P02293
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02293
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Helicase SWR1L [auth M]1,514Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: SWR1YDR334WD9651.6
EC: 3.6.4.12
UniProt
Find proteins for Q05471 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q05471
Go to UniProtKB:  Q05471
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ05471
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Actin-like protein ARP6M [auth R]438Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: ARP6YLR085CL2393L9449.13
UniProt
Find proteins for Q12509 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12509
Go to UniProtKB:  Q12509
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12509
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar protein sorting-associated protein 71N [auth S]280Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: VPS71SWC6YML041CYM8054.02C
UniProt
Find proteins for Q03433 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q03433
Go to UniProtKB:  Q03433
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03433
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
RuvB-like protein 1O [auth T],
Q [auth V],
S [auth X]
463Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RVB1TIH1TIP49AYDR190C
EC: 3.6.4.12
UniProt
Find proteins for Q03940 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q03940
Go to UniProtKB:  Q03940
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03940
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
RuvB-like protein 2P [auth U],
R [auth W],
T [auth Y]
471Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RVB2TIH2TIP49BYPL235WP1060
EC: 3.6.4.12
UniProt
Find proteins for Q12464 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12464
Go to UniProtKB:  Q12464
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12464
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains LengthOrganismImage
DNA (173-MER)J [auth I]173synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains LengthOrganismImage
DNA (173-MER)K [auth J]173synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP
Query on ADP

Download Ideal Coordinates CCD File
CA [auth T]
EA [auth U]
GA [auth V]
IA [auth W]
KA [auth X]
CA [auth T],
EA [auth U],
GA [auth V],
IA [auth W],
KA [auth X],
MA [auth Y],
U [auth M],
X [auth R]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
BEF
Query on BEF

Download Ideal Coordinates CCD File
V [auth M],
Y [auth R]
BERYLLIUM TRIFLUORIDE ION
Be F3
OGIAHMCCNXDTIE-UHFFFAOYSA-K
ZN
Query on ZN

Download Ideal Coordinates CCD File
AA [auth S],
BA [auth S]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
DA [auth U]
FA [auth U]
HA [auth V]
JA [auth W]
LA [auth Y]
DA [auth U],
FA [auth U],
HA [auth V],
JA [auth W],
LA [auth Y],
NA [auth Y],
W [auth M],
Z [auth R]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.60 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION2.1.0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom095519/Z/11/Z
Wellcome TrustUnited Kingdom209327/Z/17/Z
Cancer Research UKUnited KingdomC6913/A21608
Medical Research Council (United Kingdom)United KingdomMR/N009258/1
Medical Research Council (United Kingdom)United KingdomMR/R009023/1

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-17
    Type: Initial release
  • Version 1.1: 2018-10-24
    Changes: Data collection, Database references
  • Version 1.2: 2019-12-18
    Changes: Other
  • Version 1.3: 2024-05-15
    Changes: Data collection, Database references, Derived calculations
