6EAT

Crystallographic structure of the cyclic nonapeptide derived from the BTCI inhibitor bound to beta-trypsin in space group P 21 21 21.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.15 Å
  • R-Value Free: 0.154
  • R-Value Work: 0.144
  • R-Value Observed: 0.144

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Crystallographic structure of a complex between trypsin and a nonapeptide derived from a Bowman-Birk inhibitor found in Vigna unguiculata seeds.

Fernandes, J.P.C.Mehdad, A.Valadares, N.F.Mourao, C.B.F.Ventura, M.M.Barbosa, J.A.R.G.Freitas, S.M.

(2019) Arch Biochem Biophys 665: 79-86

  • DOI: https://doi.org/10.1016/j.abb.2019.02.013
  • Primary Citation of Related Structures:
    6E5M, 6EAT

  • PubMed Abstract:

    Natural inhibitors of proteases have been classified into different families, among them is the Bowman-Birk Inhibitor (BBI) family. Members of BBI have two structurally reactive loops that simultaneously inhibit trypsin and chymotrypsin. Here, we have investigated the binding of bovine trypsin by a cyclic nonapeptide, named PTRY9 (CTKSIPPQC), derived of the black-eyed pea trypsin/chymotrypsin inhibitor (BTCI) from Vigna unguiculata seeds. This peptide was synthetically produced with the disulfide bond restraining its conformation to mimic the reactive loop that inhibits trypsin. PTRY9 complexed to pancreatic bovine trypsin was crystallized in orthorhombic and trigonal space groups, P2 1 2 1 2 1 and P3 2 21, with maximum resolutions of 1.15 and 1.61 Å, respectively. The structures presented refinement parameters of R work  = 14.52 % and R free  = 15.59 %; R work  = 15.60 % and R free  = 18.78 %, and different surface area between the peptide and the enzyme of 1024 Å 2 and 1070 Å 2 , respectively. The binding site of the PTRY9 is similar to that found for BTCI as shown by a r.m.s.d. of 0.358 Å between the superimposed structures and the electrostatic complementary pattern at the enzyme-peptide interface. Additionally, enzyme inhibition assays show that the affinity of trypsin for PTRY9 is smaller than that for BTCI. In vitro assays revealed that, like BTCI, this synthetic peptide is not cytotoxic for normal mammary epithelial MCF-10A cells, but exerts cytotoxic effects on MDA.MB.231 invasive human breast cancer cells.


  • Organizational Affiliation

    Laboratory of Biophysics, Department of Cell Biology, University of Brasilia, Campus Darcy Ribeiro, Asa Norte, Brasília, DF, 70910-900, Brazil.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cationic trypsin223Bos taurusMutation(s): 0
EC: 3.4.21.4
UniProt
Find proteins for P00760 (Bos taurus)
Explore P00760
Go to UniProtKB:  P00760
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00760
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
9MER-PEPTIDEB [auth I]9Vigna unguiculataMutation(s): 0
UniProt
Find proteins for Q9S9E3 (Vigna unguiculata subsp. cylindrica)
Explore Q9S9E3
Go to UniProtKB:  Q9S9E3
Entity Groups
UniProt GroupQ9S9E3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
H [auth A]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
CA
Query on CA

Download Ideal Coordinates CCD File
C [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.15 Å
  • R-Value Free: 0.154
  • R-Value Work: 0.144
  • R-Value Observed: 0.144
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.834α = 90
b = 61.569β = 90
c = 67.03γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Brazilian National Council for Scientific and Technological Development (CNPq)Brazil309054/2014-1

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-13
    Type: Initial release
  • Version 1.1: 2019-03-20
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-08
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
  • Version 1.4: 2024-11-13
    Changes: Structure summary
