6EAD | pdb_00006ead

CRYSTAL STRUCTURE OF HUMAN RESPIRATORY SYNCYTIAL VIRUS FUSION GLYCOPROTEIN INHIBITOR ESCAPE VARIANT F140I STABILIZED IN THE PREFUSION STATE

• PDB DOI: https://doi.org/10.2210/pdb6EAD/pdb

• Classification: VIRAL PROTEIN
• Organism(s): human respiratory syncytial virus
• Expression System: Homo sapiens
• Mutation(s): Yes


• Deposited: 2018-08-03 Released: 2019-08-07
• Deposition Author(s): Battles, M.B., McLellan, J.S.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:
  0.230 (Depositor), 0.237 (DCC)
• R-Value Work:
  0.201 (Depositor), 0.205 (DCC)
• R-Value Observed:
  0.203 (Depositor)

Starting Model: experimental

Literature

Structural Basis for Respiratory Syncytial Virus Fusion Inhibitor Resistance

Battles, M.B., McLellan, J.S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: isothermal titration calorimetry

Macromolecule Content

• Total Structure Weight: 64.57 kDa
• Atom Count: 3,535
• Modeled Residue Count: 450
• Deposited Residue Count: 573
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fusion glycoprotein F0	A [auth F]	573	human respiratory syncytial virus	Mutation(s): 3
UniProt
Find proteins for P03420 (Human respiratory syncytial virus A (strain A2)) Explore P03420  Go to UniProtKB:  P03420
Glycosylation
Glycosylation Sites: 2

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	B [auth F], C [auth F]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N
NHE	F	2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID C8 H17 N O3 S MKWKNSIESPFAQN-UHFFFAOYSA-N
SO4	D [auth F], E [auth F]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:  0.230 (Depositor), 0.237 (DCC)
• R-Value Work:  0.201 (Depositor), 0.205 (DCC)
• R-Value Observed: 0.203 (Depositor)

Space Group: P 4₁ 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 168.95	α = 90
b = 168.95	β = 90
c = 168.95	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
MOSFLM	data reduction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2019-08-07
Deposition Author(s): Battles, M.B., McLellan, J.S.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	5T32AI007519-18
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P20GM113132

Revision History

• Version 1.0: 2019-08-07
  Type: Initial release

• Version 1.1: 2019-12-18
  Changes: Author supporting evidence
• Version 1.2: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Data collection, Derived calculations, Structure summary
• Version 1.3: 2023-10-11
  Changes: Data collection, Database references, Refinement description, Structure summary
• Version 1.4: 2024-11-20
  Changes: Structure summary
