6DQW | pdb_00006dqw

Flavobacterium johnsoniae class Id ribonucleotide reductase alpha subuint


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:
    0.251 (Depositor), 0.251 (DCC)
  • R-Value Work:
    0.206 (Depositor), 0.209 (DCC)
  • R-Value Observed:
    0.208 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6DQW

This is version 1.3 of the entry. See complete history

Literature

Structures of Class Id Ribonucleotide Reductase Catalytic Subunits Reveal a Minimal Architecture for Deoxynucleotide Biosynthesis.

Rose, H.R.Maggiolo, A.O.McBride, M.J.Palowitch, G.M.Pandelia, M.E.Davis, K.M.Yennawar, N.H.Boal, A.K.

(2019) Biochemistry 58: 1845-1860

  • DOI: https://doi.org/10.1021/acs.biochem.8b01252
  • Primary Citation Related Structures:
    6DQW, 6DQX

  • PubMed Abstract:

    Class I ribonucleotide reductases (RNRs) share a common mechanism of nucleotide reduction in a catalytic α subunit. All RNRs initiate catalysis with a thiyl radical, generated in class I enzymes by a metallocofactor in a separate β subunit. Class Id RNRs use a simple mechanism of cofactor activation involving oxidation of a Mn II 2 cluster by free superoxide to yield a metal-based Mn III Mn IV oxidant. This simple cofactor assembly pathway suggests that class Id RNRs may be representative of the evolutionary precursors to more complex class Ia-c enzymes. X-ray crystal structures of two class Id α proteins from Flavobacterium johnsoniae ( Fj) and Actinobacillus ureae ( Au) reveal that this subunit is distinctly small. The enzyme completely lacks common N-terminal ATP-cone allosteric motifs that regulate overall activity, a process that normally occurs by dATP-induced formation of inhibitory quaternary structures to prevent productive β subunit association. Class Id RNR activity is insensitive to dATP in the Fj and Au enzymes evaluated here, as expected. However, the class Id α protein from Fj adopts higher-order structures, detected crystallographically and in solution. The Au enzyme does not exhibit these quaternary forms. Our study reveals structural similarity between bacterial class Id and eukaryotic class Ia α subunits in conservation of an internal auxiliary domain. Our findings with the Fj enzyme illustrate that nucleotide-independent higher-order quaternary structures can form in simple RNRs with truncated or missing allosteric motifs.


  • Organizational Affiliation
    • Department of Chemistry , The Pennsylvania State University , University Park , Pennsylvania 16802 , United States.

Macromolecule Content

  • Total Structure Weight: 263.62 kDa
  • Atom Count: 15,313
  • Modeled Residue Count: 1,899
  • Deposited Residue Count: 2,340
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ribonucleoside-diphosphate reductase, alpha chain
A, B, C, D
585Flavobacterium johnsoniae UW101Mutation(s): 0
Gene Names: Fjoh_4065
EC: 1.17.4.1
UniProt
Find proteins for A5FCJ4 (Flavobacterium johnsoniae (strain ATCC 17061 / DSM 2064 / JCM 8514 / BCRC 14874 / CCUG 350202 / NBRC 14942 / NCIMB 11054 / UW101))
Explore A5FCJ4
Go to UniProtKB:  A5FCJ4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA5FCJ4
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:  0.251 (Depositor), 0.251 (DCC)
  • R-Value Work:  0.206 (Depositor), 0.209 (DCC)
  • R-Value Observed: 0.208 (Depositor)
Space Group: P 61
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 161.031α = 90
b = 161.031β = 90
c = 187.733γ = 120
Software Package:
Software NamePurpose
HKL-2000data scaling
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
BALBESphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM119707

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-17
    Type: Initial release
  • Version 1.1: 2019-04-24
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-01
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
