6CFZ | pdb_00006cfz

Structure of the DASH/Dam1 complex shows its role at the yeast kinetochore-microtubule interface

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.50 Å
  • Aggregation State: HELICAL ARRAY
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6CFZ

This is version 1.4 of the entry. See complete history.

Literature

Structure of the DASH/Dam1 complex shows its role at the yeast kinetochore-microtubule interface.

Jenni, S., Harrison, S.C.

(2018) Science 360: 552-558

  • DOI: https://doi.org/10.1126/science.aar6436
  • Primary Citation Related Structures:
    6CFZ

  • PubMed Abstract:

    Kinetochores connect mitotic-spindle microtubules with chromosomes, allowing microtubule depolymerization to pull chromosomes apart during anaphase while resisting detachment as the microtubule shortens. The heterodecameric DASH/Dam1 complex (DASH/Dam1c), an essential component of yeast kinetochores, assembles into a microtubule-encircling ring. The ring associates with rodlike Ndc80 complexes to organize the kinetochore-microtubule interface. We report the cryo-electron microscopy structure (at ~4.5-angstrom resolution) of a DASH/Dam1c ring and a molecular model of its ordered components, validated by evolutionary direct-coupling analysis. Integrating this structure with that of the Ndc80 complex and with published interaction data yields a molecular picture of kinetochore-microtubule attachment, including how flexible, C-terminal extensions of DASH/Dam1c subunits project and contact widely separated sites on the Ndc80 complex rod and how phosphorylation at previously identified sites might regulate kinetochore assembly.

    • Organizational Affiliation:
    • Department of Biological Chemistry and Molecular Pharmacology, Harvard Medical School, 250 Longwood Avenue, Boston, MA 02115, USA.

Macromolecule Content

  • Total Structure Weight: 116.15 kDa
  • Atom Count: 5,990
  • Modeled Residue Count: 761
  • Deposited Residue Count: 1,026
  • Unique protein chains: 10

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ask177Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0029740
UniProt
Find proteins for G0S8F9 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S8F9
Go to UniProtKB:  G0S8F9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S8F9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Dad367Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0005680
UniProt
Find proteins for G0RY74 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0RY74
Go to UniProtKB:  G0RY74
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0RY74
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Dad294Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0002350
UniProt
Find proteins for G0RZB3 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0RZB3
Go to UniProtKB:  G0RZB3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0RZB3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Duo1111Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0042930
UniProt
Find proteins for G0SAN7 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0SAN7
Go to UniProtKB:  G0SAN7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0SAN7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Dad472Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0032660
UniProt
Find proteins for G0S589 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S589
Go to UniProtKB:  G0S589
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S589
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
Dad1,Dad192Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0006450
UniProt
Find proteins for G0RYE9 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0RYE9
Go to UniProtKB:  G0RYE9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0RYE9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
Hsk361Thermochaetoides thermophilaMutation(s): 0
Find similar proteins by:
|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
Dam156Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0017540
UniProt
Find proteins for G0S2K4 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S2K4
Go to UniProtKB:  G0S2K4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S2K4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
Spc19151Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0010600
UniProt
Find proteins for G0S0N0 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S0N0
Go to UniProtKB:  G0S0N0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S0N0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
Spc34245Thermochaetoides thermophila DSM 1495Mutation(s): 0
Gene Names: CTHT_0016520
UniProt
Find proteins for G0S2A3 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S2A3
Go to UniProtKB:  G0S2A3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S2A3
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.50 Å
  • Aggregation State: HELICAL ARRAY
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcisTEM
MODEL REFINEMENTRosetta
MODEL REFINEMENTPHENIX1.12

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Damon Runyon Cancer Research FoundationUnited StatesDRG-2004-09

Revision History  (Full details and data files)

  • Version 1.0: 2018-05-02
    Type: Initial release
  • Version 1.1: 2018-05-16
    Changes: Data collection, Data processing
  • Version 1.2: 2018-05-23
    Changes: Data collection, Database references
  • Version 1.3: 2019-11-27
    Changes: Data collection
  • Version 1.4: 2024-03-13
    Changes: Data collection, Database references, Derived calculations
