6CBT | pdb_00006cbt

DnaG Primase C-terminal domain complex with SSB C-terminal peptide

• PDB DOI: https://doi.org/10.2210/pdb6CBT/pdb

• Classification: REPLICATION
• Organism(s): Escherichia coli K-12
• Expression System: Escherichia coli BL21
• Mutation(s): No


• Deposited: 2018-02-05 Released: 2019-02-06
• Deposition Author(s): Oakley, A.J., Lo, A.T.Y.
• Funding Organization(s): Australian Research Council (ARC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free:
  0.229 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.200 (Depositor), 0.201 (DCC)
• R-Value Observed:
  0.202 (Depositor)

Starting Model: experimental

Literature

DnaG Primase C-terminal domain complex with SSB C-terminal peptide

Oakley, A.J., Lo, A.T.Y.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 37.7 kDa
• Atom Count: 2,580
• Modeled Residue Count: 281
• Deposited Residue Count: 332
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA primase, single-stranded DNA-binding protein chimera	A, B	166	Escherichia coli K-12	Mutation(s): 0  Gene Names: dnaG, dnaP, parB, b3066, JW3038, ssb_1, BUE81_14300, ERS085374_00666 EC: 2.7.7.101
UniProt
Find proteins for P0ABS5 (Escherichia coli (strain K12)) Explore P0ABS5  Go to UniProtKB:  P0ABS5

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	C [auth A], D [auth A], F [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
ACY	E [auth A], G [auth B]	ACETIC ACID C2 H4 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free:  0.229 (Depositor), 0.230 (DCC)
• R-Value Work:  0.200 (Depositor), 0.201 (DCC)
• R-Value Observed: 0.202 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.284	α = 90
b = 115.841	β = 90
c = 45.742	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
MOSFLM	data reduction
SCALA	data scaling
MOLREP	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2019-02-06
Deposition Author(s): Oakley, A.J., Lo, A.T.Y.

---

Funding Organization	Location	Grant Number
Australian Research Council (ARC)	Australia	DP0877658

Revision History

• Version 1.0: 2019-02-06
  Type: Initial release

• Version 1.1: 2020-01-01
  Changes: Author supporting evidence
• Version 1.2: 2023-10-04
  Changes: Data collection, Database references, Derived calculations, Refinement description
