6A7Y | pdb_00006a7y

Solution structure of an intermolecular leaped V-shape G-quadruplex

  • Classification: DNA
  • Organism(s): Sterkiella nova
  • Expression System: synthetic construct
  • Mutation(s): No

  • Deposited: 2018-07-05 Released: 2018-12-12
  • Deposition Author(s): Wan, C.J., Zhang, N.
  • Funding Organization(s): National Science Foundation (China), National Natural Science Foundation of China

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 10
  • Selection Criteria: structures with the lowest energy

wwPDB Validation 3D Report Full Report

Validation slider image for 6A7Y

This is version 1.3 of the entry. See complete history

Literature

NMR solution structure of an asymmetric intermolecular leaped V-shape G-quadruplex: selective recognition of the d(G2NG3NG4) sequence motif by a short linear G-rich DNA probe.

Wan, C.Fu, W.Jing, H.Zhang, N.

(2019) Nucleic Acids Res 47: 1544-1556

  • DOI: https://doi.org/10.1093/nar/gky1167
  • Primary Citation Related Structures:
    6A7Y

  • PubMed Abstract:

    Aside from classical loops among G-quadruplexes, the unique leaped V-shape scaffold spans over three G-tetrads, without any intervening residues. This scaffold enables a sharp reversal of two adjacent strand directions and simultaneously participates in forming the G-tetrad core. These features make this scaffold itself distinctive and thus an essentially more accessible target. As an alternative to the conventional antisense method using a complementary chain, forming an intermolecular G-quadruplex from two different oligomers, in which the longer one as the target is captured by a short G-rich fragment, could be helpful for recognizing G-rich sequences and structural motifs. However, such an intermolecular leaped V-shape G-quadruplex consisting of DNA oligomers of quite different lengths has not been evaluated. Here, we present the first nuclear magnetic resonance (NMR) study of an asymmetric intermolecular leaped V-shape G-quadruplex assembled between an Oxytricha nova telomeric sequence d(G2T4G4T4G4) and a single G-tract fragment d(TG4A). Furthermore, we explored the selectivity of this short fragment as a potential probe, examined the kinetic discrimination for probing a specific mutant, and proposed the key sequence motif d(G2NG3NG4) essential for building the leaped V-shape G-quadruplexes.


  • Organizational Affiliation
    • High Magnetic Field Laboratory, Chinese Academy of Sciences, Hefei 230031, China.

Macromolecule Content

  • Total Structure Weight: 7.57 kDa
  • Atom Count: 503
  • Modeled Residue Count: 24
  • Deposited Residue Count: 24
  • Unique nucleic acid chains: 2

Macromolecules

Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*GP*TP*TP*TP*TP*GP*GP*GP*GP*TP*TP*TP*TP*GP*GP*GP*G)-3')18Sterkiella nova
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*TP*GP*GP*GP*GP*A)-3')6Sterkiella nova
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 10
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (China)China31600621
National Natural Science Foundation of ChinaChina21372223
National Natural Science Foundation of ChinaChinaU1232145

Revision History  (Full details and data files)

  • Version 1.0: 2018-12-12
    Type: Initial release
  • Version 1.1: 2019-07-10
    Changes: Data collection, Database references
  • Version 1.2: 2023-06-14
    Changes: Database references, Other
  • Version 1.3: 2024-05-15
    Changes: Data collection, Database references
