5TGQ | pdb_00005tgq

Restriction-modification system Type II R.SwaI, DNA free


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.88 Å
  • R-Value Free:
    0.279 (Depositor), 0.283 (DCC)
  • R-Value Work:
    0.198 (Depositor), 0.204 (DCC)
  • R-Value Observed:
    0.202 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5TGQ

This is version 1.4 of the entry. See complete history

Literature

DNA recognition by the SwaI restriction endonuclease involves unusual distortion of an 8 base pair A:T-rich target.

Shen, B.W.Heiter, D.F.Lunnen, K.D.Wilson, G.G.Stoddard, B.L.

(2017) Nucleic Acids Res 45: 1516-1528

  • DOI: https://doi.org/10.1093/nar/gkw1200
  • Primary Citation Related Structures:
    5TGQ, 5TGX, 5TH3

  • PubMed Abstract:

    R.SwaI, a Type IIP restriction endonuclease, recognizes a palindromic eight base pair (bp) symmetric sequence, 5΄-ATTTAAAT-3΄, and cleaves that target at its center to generate blunt-ended DNA fragments. Here, we report three crystal structures of SwaI: unbound enzyme, a DNA-bound complex with calcium ions; and a DNA-bound, fully cleaved complex with magnesium ions. We compare these structures to two structurally similar ‘PD-D/ExK’ restriction endonucleases (EcoRV and HincII) that also generate blunt-ended products, and to a structurally distinct enzyme (the HNH endonuclease PacI) that also recognizes an 8-bp target site consisting solely of A:T base pairs. Binding by SwaI induces an extreme bend in the target sequence accompanied by un-pairing and re-ordering of its central A:T base pairs. This result is reminiscent of a more dramatic target deformation previously described for PacI, implying that long A:T-rich target sites might display structural or dynamic behaviors that play a significant role in endonuclease recognition and cleavage.


  • Organizational Affiliation
    • Division of Basic Sciences, Fred Hutchinson Cancer Research Center, 1100 Fairview Ave. North, Seattle, WA, USA.

Macromolecule Content

  • Total Structure Weight: 27.29 kDa
  • Atom Count: 2,015
  • Modeled Residue Count: 226
  • Deposited Residue Count: 226
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
R.SwaI protein226Staphylococcus warneriMutation(s): 0
UniProt
Find proteins for A0A1S4NYF7 (Staphylococcus warneri)
Explore A0A1S4NYF7
Go to UniProtKB:  A0A1S4NYF7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S4NYF7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TRS

Query on TRS



Download:Ideal Coordinates CCD File
F [auth A]2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
ACT

Query on ACT



Download:Ideal Coordinates CCD File
G [auth A],
H [auth A]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
CA

Query on CA



Download:Ideal Coordinates CCD File
B [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.88 Å
  • R-Value Free:  0.279 (Depositor), 0.283 (DCC)
  • R-Value Work:  0.198 (Depositor), 0.204 (DCC)
  • R-Value Observed: 0.202 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.386α = 90
b = 65.225β = 90
c = 67.567γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01 GM105691

Revision History  (Full details and data files)

  • Version 1.0: 2016-12-21
    Type: Initial release
  • Version 1.1: 2017-06-21
    Changes: Database references
  • Version 1.2: 2017-09-20
    Changes: Author supporting evidence
  • Version 1.3: 2019-12-25
    Changes: Author supporting evidence
  • Version 1.4: 2024-03-06
    Changes: Data collection, Database references, Derived calculations
